Corning 036TWP-T4190D20 | FREEDM Loose Tube, Gel-Free Cable, Plenum 36 F, 50 µm Multimode (OM4)
Regular price
$18.63
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Corning 036TWP-T4190D20 | FREEDM Loose Tube, Gel-Free Cable, Plenum...
Regular price
$18.63
Unit price
Brand: Corning
|
SKU:
373-COROM4-LTP-36
Regular price
$18.63
Unit price
Shipping calculated at checkout.
Description
Description
Corning 036TWP-T4190D20 | FREEDM Loose Tube, Gel-Free Cable, Plenum 36 F, 50 µm Multimode (OM4)
Corning - 036TWP-T4190D20 - Features
- Craft-friendly cable preparation
- Stable performance and compatibility with all common fiber types
- Quick and easy identification
- Requires no grounding or bonding
- Outdoor lashed aerial and duct
Specifications
Specifications
Corning - 036TWP-T4190D20 - Specifications
| Product Number | 036TWP-T4190D20 |
|---|---|
| EAN Code | 4056418173092 |
| Cable Type | Loose Tube |
| Environment | Indoor/Outdoor |
| Product Type | Dielectric |
| Fiber Category | 50 µm MM (OM4) |
| Flame Rating | Plenum (OFCP) |
| Application | Aerial, Direct Buried, Duct, General purpose, Horizontal, Vertical Riser, Plenum |
| RoHS | Free of hazardous substances according to RoHS 2011/65/EU |
| Approvals and Listings | National Electrical Code® (NEC®) OFNP |
| Common Installations | Outdoor aerial and duct, indoor vertical riser and general purpose horizontal according to National Electrical Code® (NEC®) Article 770 |
| Temperature Range, Installation | 0 °C to 60 °C (32 °F to 140 °F ) |
| Temperature Range, Operation | -40 °C to 70 °C (-40 °F to 158 °F ) |
| Temperature Range, Storage | -40 °C to 70 °C (-40 °F to 158 °F ) |
| Central Element | Dielectric |
| Fiber Count | 36 |
| Number of Ripcords | 2 |
| Outer Jacket Color | Black |
| Outer Jacket Material | Flame-Retardant, UV-Resistant |
| Tensile Strength Elements and/or Armoring - Layer 1 | Dielectric strength members |
| Buffer Tube Color | Aqua |
| Buffer Tube Diameter | 3 mm (0.12 in) |
| Number of Active Tubes | 3 |
| Number of Filling Elements | 3 |
| Number of Tube Positions | 6 |
| Tape | Water-swellable |
| Fiber Coloring | Blue, Orange, Green, Brown, Slate, White, Red, Black, Yellow, Violet, Rose, Aqua |
| Fibers per Tube | 12 |
| Max. Tensile Strength, Long-Term | 810 N (182.1 lbf) |
| Max. Tensile Strength, Long-Term | 810 N (182.1 lbf) |
| Max. Tensile Strength, Short-Term | 2700 N (606.98 lbf) |
| Min. Bend Radius Installation | 171 mm (6.73 in) |
| Min. Bend Radius Operation | 114 mm (4.49 in) |
| Nominal Outer Diameter | 13.4 mm |
