Brand: Corning
|
SKU:
370-COROS2-LTA2.0144
Corning 144ZD9-T1301-MA | MIC 250 2.0 Interlocking Armored Cable 144 F, SMF-28 Ultra fiber, Single-mode (OS2)
Regular price
$12.42
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Corning 144ZD9-T1301-MA | MIC 250 2.0 Interlocking Armored Cable 1...
Regular price
$12.42
Unit price
Brand: Corning
|
SKU:
370-COROS2-LTA2.0144
Regular price
$12.42
Unit price
Shipping calculated at checkout.
Description
Description
Corning 144ZD9-T1301-MA | MIC 250 2.0 Interlocking Armored Cable 144 F, SMF-28 Ultra fiber, Single-mode (OS2)
Specifications
Specifications
Corning - 144ZD9-T1301-MA - Product Categories
- Fiber Optic Cables
- Indoor
- Indoor Plenum Cables
Corning - 144ZD9-T1301-MA - Specifications
| Brand Name | Corning |
|---|---|
| Manufacturer Part Number | 144ZD9-T1301-MA |
| Item Description | MIC 250 2.0 Interlocking Armored Cable 144 F, SMF-28 Ultra fiber, Single-mode (OS2) |
| General Specifications | - |
| Product Number | 144ZD9-T1301-MA |
| Environment | Indoor |
| Cable Type | Loose Tube |
| Product Type | Distribution |
| Fiber Category | Single-mode (OS2) |
| Application | General Purpose Horizontal, Plenum, Vertical Riser |
| Fiber Count | 144 |
| Standards | - |
| RoHS | Free of hazardous substances according to RoHS 2011/65/EU |
| Environmental Conditions | - |
| Temperature Range, Installation | 0°C to 60°C (32°F to 140°F ) |
| Temperature Range, Operation | 0°C to 70°C (32°F to 158°F ) |
| Temperature Range, Storage | -40°C to 70°C (-40°F to 158°F ) |
| Cable Design | - |
| Central Element | Dielectric |
| Fiber Count | 144 |
| Outer Jacket Color | Yellow |
| Outer Jacket Material | Flame-retardant |
| Tensile Strength Elements and/or Armoring - Layer 1 | Dielectric strength members |
| Tensile Strength Elements and/or Armoring - Layer 2 | Interlocking Armor |
| Buffer Tube Diameter | 2mm (0.08in) |
| Fiber Bundle Coloring | Blue, Orange, Green, Brown, Slate, White, Red, Black, Yellow, Violet, Rose, Aqua |
| Number of Active Tubes | 12 |
| Fibers per Tube | 12 |
| Color Code Standards | Telcordia |
| Mechanical Specifications | - |
| Max. Tensile Strength, Short-Term | 660N (148.37lbf) |
| Min. Bend Radius Installation | 249mm (9.8in) |
| Min. Bend Radius Operation | 160mm (6.3in) |
| Nominal Outer Diameter | 16.6mm (0.65in) |
| Optical Characteristics | - |
| Fiber Code | Z |
| Fiber Name | SMF-28 Ultra fiber |
| Fiber Type | Single-mode |
| Performance Option Code | 01 |
| Maximum Attenuation | 0.4 dB/km / 0.4 dB/km / 0.3 dB/km |
| Wavelengths | 1310 nm / 1383 nm / 1550 nm |
| Fiber Category | ITU-T G.657.A1 |
| Dimensions | - |
| Cable Weight | 212.91kg/km (143.07lb/1000 ft) |
