Brand: Corning
|
SKU:
667846
Corning 7979-OM4-B70-03M | Uniboot Jumper in a Box
Regular price
$4,193.81
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Corning 7979-OM4-B70-03M | Uniboot Jumper in a Box
Regular price
$4,193.81
Unit price
Description
Description
Corning 7979-OM4-B70-03M | Uniboot Jumper in a Box 50 µm multimode (OM4), 3 m, pack of 70
Corning - 7979-OM4-B70-03M - Features
- Bags that are connected with individual jumpers in an easy payout
- Easy inventory management and inventory control
- Compact box design that fits the same profile as copper cable boxes
- Fits along side standard copper cable payout boxes, easy to store on shelves
- Easy to identify box labeling of jumper type/QR code
- Quick visual identification makes it easy to find the correct jumper very quickly, type and length
- Identifier that lets customer know it is time to reorder
- Helps control inventory and reduces risk of running out of product
- Reduced individual jumper packaging
- Less waste and less time to unpackage
- Sequential number of each jumper in the payout box
- Helps control inventory
- Re-sealable individual bags
- Can re-package and keep new LC uniboots safe even after the bag is opened and separated from the reel of bags and the box
Specifications
Specifications
Corning - 7979-OM4-B70-03M - Product Categories
- Shop by Manufacturer/Corning
- Communications
- Fiber Optic Cabling Infrastructure
- Fiber Optic Cable Assemblies
- Data Communications and Networking
- Patch Cords
- Fiber Optic Patch Cords
- Fiber Optic Cable Assemblies
- Indoor Cable Assemblies
Corning - 7979-OM4-B70-03M - Specifications
| General Specifications | - |
|---|---|
| Product Number | 7979-OM4-B70-03M |
| EAN Code | 4056418138398 |
| Flame Rating | Riser (OFNR) |
| Fiber Category | 50 µm MM (OM4) |
| Cable Assembly Type | Two Fiber |
| Application | Data Center LAN/SAN, Enterprise Networks |
| Cable Type | DFX 250 |
| Standards | - |
| RoHS | Free of hazardous substances according to RoHS 2011/65/EU |
| Fiber Standards | TIA/EIA-492AAAC-A, Tested with minEMBc method to TIA/EIA-455-220, IEC 60793-2-10 Type A1a.2 Ed.2.0, IEC 60793-1-49 Ed.2.0, ITU-T G.651, ISO/IEC 11801 Ed.2.2 Cat. OM3 |
| Standards | - |
| Fiber Standards | TIA/EIA-492AAAC-A, Tested with minEMBc method to TIA/EIA-455-220, IEC 60793-2-10 Type A1a.2 Ed.2.0, IEC 60793-1-49 Ed.2.0, ITU-T G.651, ISO/IEC 11801 Ed.2.2 Cat. OM3 |
| Design | - |
| Fiber Count | 2 |
| Outer Jacket Material | Flame-retardant |
| Fiber Type | Multimode |
| Mechanical Specifications | - |
| Minimum Bend Radius | 10 mm (0.39 in) |
| Cable Length | 3 m (9.84 ft) |
| Optical Characteristics | - |
| Fiber Code | Q |
| Fiber Type | Multimode |
| Fiber Compliance | IEC 60793-2-10 for A1a class 50/125 multimode fibers; TIA/EIA 492AAAD (OM4); ITU-T Recommendation G.651; ISO/IEC 11801 Ed.2.2 Grade OM4 |
| Fiber Core Diameter | 50 µm |
| Minimum Effective Modal Bandwidth (EMB) | 4700 MHz*km / - |
| Maximum Attenuation | 2.8 dB/km / 1.0 dB/km |
| Min. Overfilled Launch (OFL) Bandwidth | 1500 MHz*km / 500 MHz*km |
| Serial 1 Gigabit Ethernet | 1000 MHz*km / 600 MHz*km |
| Serial 10 Gigabit Ethernet | 600 MHz*km / - |
| Wavelengths | 850 nm / 1300 nm |
| Fiber Category | OM4 Extended Distance |
| Specifications - Connector A | - |
| Boot Color | Aqua |
| Connector Type | LC Uniboot |
| Ferrule Material | Ceramic |
| Housing Color | Black |
| Housing Material | Composite |
| Specifications - Connector B | - |
| Boot Color | Aqua |
| Connector Type | LC Uniboot |
| Ferrule Material | Ceramic |
| Housing Color | Black |
| Dimensions | - |
| Outer Diameter | 2 mm (0.08 in) |
| Ordering Information | - |
| Packing Type | Cardboard box |
| Units per Delivery | 70/1 |
| Type | Fiber Patch Cable |
| Transmission Mode | Multimode |
| Cable Construction | Duplex |
| End Connector - A | LC Uniboot |
| End Connector - B | LC Uniboot |
| End Type A | Ceramic Ferrule |
| End Type B | Ceramic Ferrule |
| Jacket Rating | CM |
| Length - Metric | 3m |
| Length | 9.8 ft. |
| Color | Aqua |
