Corning A757512TPNBBU100F | 12-Fiber Plug & Play, Universal Low-Loss Trunk Cable, 36 In. Leg, 100 Ft., Aqua

Standards
National Electrical Code (NEC) OFNP, CSA FT-6
NFPA 262 (for plenum, riser and general building applications)
ROHS Compliant

• Application: Data Center LAN/SAN
• Flame Rating: Plenum (OFNP)
• Cable Type: Indoor
• Factory-terminated solutions
• Universal-wired modular system components
• Low insertion loss performance
• Corning ClearCurve 50 ?m Optical Fiber
• 100G Ready performance
• Maximum skew of 0.75 ns
• Protective pulling grip

Mechanical Characteristics Cable

• Nominal Outer Diameter: 5.5 mm (± 0.3 mm) (0.22 in (± 0.01 in)
• Min. Bend Radius Installation: 82.5 mm (3.3 in)
• Min. Bend Radius Operation: 27.5 mm (1.08 in)
• Max. Tensile Strength for Installation: 440 N
• Weight: 32 kg/km (71 lb/1000 ft)

Optical Characteristics (cabled)

• Fiber Compliance: IEC 60793-2-10 for A1a class 50/125 multimode fibers; TIA/ EIA 492AAAC-A (OM3); ITU-T Recommendation G.651; ISO/ IEC 11801 Grade OM3
• Wavelengths: 850 nm / 1300 nm
• Maximum Attenuation: 2.8 dB/km / 1.0 dB/km
• Min. Overfilled Launch (OFL) Bandwidth: 1500 MHz*km / 500 MHz*km
• Minimum Effective Modal Bandwidth (EMB): 2000 MHz*km / -
• Serial 1 Gigabit Ethernet: 1000 m / 600 m
• Serial 10 Gigabit Ethernet: 300 m / -
• Induced Attenuation @ 7.5 mm Radius: < 0.2 dB (2 turns; 7.5 mm radius; 850 nm)
• Skew: < 0.75 ns @ 300 m
