Corning CCH-CS24-B3-P00 Cch Pigtailed Splice Cassette24 F, Lc Apc Duplex, Single-mode (os2), Single-fiber (250 Um)

CCH pigtailed splice cassettes enable faster field splicing and easy modular management of connectorization within the housing. The CCH pigtailed splice cassettes are preloaded and pre-routed for quick fusion splicing of either individual or ribbon fib er pigtails, using the same space-saving platform as the standard CCH splice cassette. The pre-routed pigtailed cassettes reduce field labor by streamlining the features and components of the pigtail cassette to allow for efficiencies in the field. The y are prepped with a 2 meter pigtail assembly with all pre-existing CCH panel connector options. The pigtailed cassettes have 900 um at the connector panel for added durability and colored 250 um for ease of splicing as well as having strain relief pre -applied to the assemblies from the manufacturing facility. With the pigtailed cassette, the field will also enjoy the elimination of individual splice trays or separate splice housings, as well as allowing splicing to be done away from the rack housin g in a suitable workspace as needed. The modular design makes it easy to access the fiber in an individual cassette without disturbing the other fibers in the housing. Each cassette is shipped with the pigtailed CCH adapter panel of choice, one rail fo r use with CCH-01U/2U/3U housings, and two rails used with CCH-04U housings. Grommets and cable ties for additional strain relief and protective braided tubing for incoming cable are also included. Splicing cassettes ship with the appropriate quantity and type of heat-shrink splice protectors. Many of our products are highly configurable. If you don’t see what you are looking for, review the ordering matrix contained in the family spec sheet or Customer Care at 1-800-743-2675.
