Brand: Corning | SKU: 519139

Corning ECM-UM48-93-93Q | EDGE Conversion Modules

Name: Corning ECM-UM48-93-93Q | EDGE Conversion Modules
Brand: Anixter
SKU: 519139
Price: 2889.33 USD
Availability: InStock

$2,889.33

Description

Corning ECM-UM48-93-93Q | EDGE Conversion Modules 48 F, MTP (pinned) to MTP (pinned), 50 µm multimode (OM4)

VFL-compatible shuttered LC adapters
Creates one-hand operation and decreases time needed to test and troubleshoot a link
Rear-loading capability
Decreases the time to prepare and install modules into fiber housings
High density
Low insertion loss performance
Improved performance specs allow for more mated pairs and/or longer link distances
Corning CleanAdvantage technology and optimised dust cap
Eliminates the need for scoping and cleaning prior to initial field connection

General Specifications	-
Product Number	ECM-UM48-93-93Q
EAN Code	4042673629375
Product Type	Panels and Modules
Fiber Category	50 µm MM (OM4)
Application	Data Center LAN/SAN
Standards	-
RoHS	Free of hazardous substances according to RoHS 2011/65/EU
Environmental Conditions	-
Temperature Range, Operation	-10 °C to 60 °C (14 °F to 140 °F )
Design	-
Fiber Count	48
Adapter Type Back	MTP
Adapter Color Back	Aqua
Adapter Color Front	Aqua
Adapter Type Front	Shuttered MTP 6x8F
Housing Type	Panels and Modules
Number of Adapters per Panel	6
Cable Design	-
Fiber Count	48
Polarity	TIA-568 Type-B
Optical Specification - Hardware	-
Module Insertion Loss, Max	0.5 dB
Wavelengths	850 nm / 1300 nm
Fiber Category	50 µm MM (OM4)
Connector Specs	-
Ferrule Material	Composite
Specifications - Connector A	-
Connector Type	MTP (pinned)
Ferrule Material	Composite
Specifications - Connector B	-
Connector Type	MTP (pinned)
Ferrule Material	Composite
Ordering Information	-
Weight	11 kg
Units per Delivery	1/1"
