Corning SOC-SCA-2MM-SM | FuseLite Connector, SC, 2.0 mm, Jacketed
Regular price
$25.31
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Corning SOC-SCA-2MM-SM | FuseLite Connector, SC, 2.0 mm, Jacketed
Regular price
$25.31
Unit price
Description
Description
Corning SOC-SCA-2MM-SM | FuseLite Connector, SC, 2.0 mm, Jacketed Single-mode (OS2) APC
In applications where fusion splicing is not required, Corning continues to recommend UniCam HighPerformance Connectors, which eliminate the need for capital investments in equipment.
Corning - SOC-SCA-2MM-SM - Features
- Broad operating temperature range (-40°C to +75°C)
- Utility and flexibility
- Factory-polished end face
- Consistent optical performance
- Fusion splice connectivity
- Ideal for reflectance-sensitive applications
- Splice protection within connector body
- No splice trays required
- Utility and flexibility
- Consistent optical performance
- Ideal for reflectance-sensitive applications
- No splice trays required
Specifications
Specifications
Corning - SOC-SCA-2MM-SM - Product Categories
- Shop by Manufacturer/Corning
- Hardware
- Tools and Supplies
- Miscellaneous
- DataComm
- Fiber Optic Connectivity
- Fiber Optic Connectors
- Fiber Optic Connectivity
- Connectors
Corning - SOC-SCA-2MM-SM - Specifications
| General Specifications | - |
|---|---|
| Product Number | SOC-SCA-2MM-SM |
| EAN Code | 4056418150383 |
| Fiber Category | Single-mode (OS2) |
| Product Type | Field-Installable Connectors |
| Compatibility | SC |
| Corning Logo | Yes |
| Keyed (security) | No |
| Technology | Fuse-On |
| Standards | - |
| RoHS | Free of hazardous substances according to RoHS 2011/65/EU |
| Approvals and Listings | Telcordia GR-326-CORE and GR-1081-CORE compliant |
| Environmental Conditions | - |
| Temperature Range, Operation | -40 °C to -40 °C (-40 °F to -40 °F ) |
| Design - Connector | - |
| Connector Type | SC |
| Housing Color | Green |
| Boot Color | Green |
| Ferrule Material | Composite |
| Pinned | No |
| Optical Specifications - Connector | - |
| Polish | APC |
| Insertion Loss, Max. | 0.3 dB |
| Reflectance | < -65 dB |
| Insertion Loss, Typical | 0.15 dB |
| Ordering Information | - |
| Packaging | Individual Pack |
| Units per Delivery | 1/1" |
