DSC PC585PCB6W | Keyboard For Controller
Description
Description
This product meets the requirements of Class II, Grade 2 equipment as per EN50131- 1:1997 and prEN50131-1:2004 Standards. PC5108 may be installed in the same metallic cabinet as the alarm controller/power supply (model Power UC1, PC5003C) or in a separate enclosure (PC4003C). Internal and/or external wiring for the PC5108 shall be routed, supported, clamped or secured in a manner that reduces the likelihood of (a) excessive strain on wire and terminal connections, (b) loosening of terminal connections, and (c) damage of conductor insulation.
Specifications
Specifications
DSC - PC585PCB6W - Specifications
| Weight | 1 lbs |
|---|---|
| Dimensions | 10 × 10 × 10 in |
| Temperature range | -10°C to + 55°C |
| Relative Humidity | 93% non condensing |
| Input rating | 12VDC/135mA |
| Board current draw | 35mA |
| Board dimensions | 45mm x 92mm |
| VAUX output ratings | 12VDC, -15%/ +10% when Input voltage is between 85% to110% of rated value and output current is between 0mA- 100mA max. |
