Dura-Line 20001451 | Enterprise Blown Fiber Cable, OS2 Single-Mode, Plenum, 48 Fiber
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Description
Description
Eabf cables are designed by afl to offer the most rugged and reliable enterprise-based blown fiber solution in the market today. The patent pending cable design combines a light-weight, high-drag jacketing system that allows the cable to be blown long distances. The cable series also features additional attributes that set this product above and beyond traditional blown fiber cables. These enhanced features include mechanical strengthening that permits the cable to comply with industry-standard premise interconnect specifications. In addition, the eabf cable series feature flame-resistance characteristics which result in stand-alone riser and plenum rated options suitable for routing outside of the micro-duct system. Because of these mechanical, environmental and optical qualifications, eabf cables can also be installed in third-party, flame-rated duct and pathway systems. Optimized for high-density terminations for excellent integration with mpo-based and mass-fusion spliced connectivity solutions; Environment-safe materials reduces concern for handling of cables; Cables can be de-installed and reused to meet leed-design guidelines for green building initiatives.
Specifications
Specifications
Dura-Line - 20001451 - Product Categories
- Network Cabling Infrastructure
- Fiber Optic Cabling Infrastructure
- Fiber Optic Cable
- Indoor/Outdoor Fiber Cable
Dura-Line - 20001451 - Specifications
| Manufacturer Part Number | 20001451 |
|---|---|
| Manufacturer | Dura-Line |
| Application | Backbone Distribution; Horizontal Distribution |
| Armored | Non-Armored |
| Bend Radius | 1.2 in. (30mm) |
| Cable Type | Tight Buffered |
| Cable Weight | 5.9 lb./1000 ft. (8.8kg/km) |
| Fiber Count | 48 |
| Fiber Optic Mode | Single-mode |
| Fiber Type | OS2 |
| Fire Rating | Plenum |
| Operating Temperature - Maximum | 70 |
| Operating Temperature - Minimum | -40 |
| Outer Diameter | 0.15 in. (3.8mm) |
| Outside Diameter | 0.15 in. |
| Product Type | Micro Cable |
| Temperature Rating | -40 to +70 C |
| Tensile Strength | 22 lb.-ft. (100N) |
| Transmission Mode | Singlemode |
| Water Blocking | Yes |
