Brand: Eaton Power Quality
|
SKU:
512981
Eaton Power Quality 9PX8KTF5 | UPS, Network Card Included, 9U, 8 KVA, 7.2 KW, Hardwired Input, Outputs: (18) 5-20R, (2) L6-30R, 208V
Regular price
$12,602.53
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Eaton Power Quality 9PX8KTF5 | UPS, Network Card Included, 9U, 8 KV...
Regular price
$12,602.53
Unit price
Brand: Eaton Power Quality
|
SKU:
512981
Regular price
$12,602.53
Unit price
Shipping calculated at checkout.
Description
Description
Eaton Power Quality 9PX8KTF5 | UPS, Network Card Included, 9U, 8 KVA, 7.2 KW, Hardwired Input, Outputs: (18) 5-20R, (2) L6-30R, 208V
Specifications
Specifications
Eaton Power Quality - 9PX8KTF5 - Specifications
| Product Name | Eaton 9PX UPS |
|---|---|
| Catalog Number | 9PX8KTF5 |
| UPC | 743172040459 |
| Product Length/Depth | 17.3 in |
| Product Height | 15.3 in |
| Product Width | 30 in |
| Product Weight | 300 lb |
| Compliances | FCC Part 15 CE Marked CISPR22 Class A / FCC part 15 Class A |
| Certifications | NOM cULus Listed IEC 62040-2:2006 Cat C2 ENERGY STAR certified |
| Battery management,Battery replacement,Battery type,Extended battery capability | ABM technology (3-stage charging extends battery service life by 50% and provides advance warning for battery replacement),Hot-swappable internal batteries and extended battery modules (EBMs),Sealed, lead-acid,Add up to 5 extended battery modules (EBM). Part number 9PXEBM240RT. Add up to 12 EBMs with 240V supercharger module SC240RT. |
| Receptacle | (18) 5-20R, (2) L6-30R |
| Topology | Online/Double-conversion |
| Input connection | Hardwired |
| Input nominal voltage | 208V default (200/208/220/230/240/250V) |
| Communication | Web/SNMP in MiniSlot expansion port + 1 USB port + 1 serial RS232 port + 1 mini-terminal block for remote ON/ofF + 1 mini-terminal block for remote power off + 1 mini-terminal block for output relay Communication slot |
| Expansion slots | (1) Mini-Slot (MS) expansion port with Gigabit Network Card (NETWORK-M3) included |
| Ethernet interface | Yes |
| Software compatibility | Intelligent Power Software Suite |
