Brand: Eaton Power Quality
|
SKU:
10335977
Eaton Power Quality FAZ-C20/2-RT | Current Limiting Miniature Circuit Breaker
Regular price
$511.13
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Eaton Power Quality FAZ-C20/2-RT | Current Limiting Miniature Circu...
Regular price
$511.13
Unit price
Brand: Eaton Power Quality
|
SKU:
10335977
Regular price
$511.13
Unit price
Shipping calculated at checkout.
Description
Description
Eaton Power Quality FAZ-C20/2-RT | Current Limiting Miniature Circuit Breaker
Current Limiting Miniature Circuit Breaker, 277/480 VAC, 20 A, 15 kA Interrupt, 2 Poles, 5-10X/C-Curve/Thermal Magnetic Trip.
Eaton Power Quality - FAZ-C20/2-RT - Features
- Current limiting design provides fast short-circuit interruption that reduces the let-through energy, which can damage the circuit
- Suitable for branch circuit device protection
- Thermal magnetic over current protection
- Three levels of short circuit protection, categorized by B, C and D curves
- Trip-free design breaker can not be defeated by holding the handle in the On position
- Captive screws cannot be lost
- Field installable shunt trip and auxiliary switch subsequent mounting
- Contact position indicator (red/green)
- Possibility for sealing the toggle in "On/Off" position
Specifications
Specifications
Eaton Power Quality - FAZ-C20/2-RT - Specifications
| Mounting Type | DIN Rail |
|---|---|
| Voltage Rating | 277/480 |
| Connection Type | Ring Tongue |
| Frequency Rating | 50/60 |
| Temperature Rating | 40 |
| Type | Current Limiting |
| Series | FAZ-RT |
| Dimensions | 2.97 in W x 1.39 in D x 4.13 in H |
| Trip Range | 5 to 10X |
| Actuator Type | Toggle |
| Amperage Rating | 20 |
