Electro-Voice ELX200-18SP-US | 18? 1200W Powered Subwoofer (Black, ...
Description
Description
The black Electro-Voice ELX200-18SP is an 18” 1200W powered subwoofer designed to provide dependable low-frequency amplification, easy installation, and convenient control for sound engineers and performers in live stage applications, theaters, DJ setups, and mobile rigs. It features 1200W of Class-D amplification, which drives an 18” woofer to produce a frequency range of 40 to 145 Hz.
Route a balanced source such as a stereo mixer output via two XLR-1/4” combo jack inputs, then utilize the two XLR Link outputs to connect to full-range speakers. A rear-panel knob and LCD allow access to master volume and the on-board DSP functions, which include three easy-setup presets, five user-programmable presets, adjustable low-pass frequency, and metering. Adjust parameters via the single-knob interface and LCD, or control the subwoofer via Bluetooth.
Its plywood enclosure and steel grille ensure durability and stability. Built-in carry handles allow easy loading and unloading at gigs. Mount a full-range speaker above the subwoofer via the top-panel M20 threaded hole. The ELX200-18SP ships with a power cable.
Electro-Voice - ELX200-18SP-US - Features
- 18? woofer
- 40 to 145 Hz frequency range
- 1200W of Class-D amplification
- 2 x XLR-1/4? combo jack inputs
- 2 x XLR Link outputs
- Adjustable low-pass frequency at 80/100/120/150 Hz
- On-board DSP and master volume control
- Three preset modes and five user-programmable presets
- Single-knob user interface and LCD
- Supports configuration via Bluetooth
- M20 thread for pole-mounting a speaker on top of subwoofer
- Integrated carry handles
Specifications
Specifications
Electro-Voice - ELX200-18SP-US - Specifications
| Brand Name | Electro-Voice |
|---|---|
| Manufacturer Part Number | ELX200-18SP-US |
| Item Description | 18? 1200W Powered Subwoofer (Black, Single) |
| PA Speaker | Configuration Active Subwoofer |
| Drivers | LF Driver 1 x 18" / 45.72 cm Woofer |
| Performance | Frequency Range 40 Hz to 145 Hz -10 dB Frequency Response 47 Hz to 105 Hz -3 dB Maximum SPL 130 dB |
| Connectivity | Audio I/O 2 x Combo XLR-1/4" TRS Input 2 x XLR 3-Pin Output |
| Power | AC Input Power 100 to 240 VAC, 50 / 60 Hz Current Consumption 1.8 A |
| Dimensions | 23.3 x 20 x 22.5" / 59.2 x 50.8 x 57.1 cm |
| Weight | 64 lb / 29 kg |
| Construction Material | Metal Grille, Plywood |
