Encore Wire C0431A.41.10 | Power-Limited Tray Cable, 22 AWG, 2 Conductor, Stranded, Tin-Plated Copper Conductor, -20 to 105 C, 300 V
Regular price
$340.57
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Encore Wire C0431A.41.10 | Power-Limited Tray Cable, 22 AWG, 2 Cond...
Regular price
$340.57
Unit price
Description
Description
Encore Wire C0431A.41.10 | Power-Limited Tray Cable, 22 AWG, 2 Conductor, Stranded, Tin-Plated Copper Conductor, -20 to 105 C, 300 V
Power-Limited Tray Cable, Conductor Size: 22 AWG, Conductor Count: 2 Conductor, Conductor Type: Stranded, Conductor Material: Tin-Plated Copper, Temperature Rating: -20 to 105 C, Insulation Material: PVC, Insulation Thickness: 0.013 in., Shield Type: Unshielded, Jacket Material: PVC, Jacket Color: Gray, Voltage: 300 V, Length: 1000 ft., Conductor Stranding: 7 x 30 Strand, Dimensions: OD: 0.185 in., Special Rating: CSA, UL
Specifications
Specifications
Encore Wire - C0431A.41.10 - Applications
- Supports cable tray installations where a power-limited tray cable is required.
- Designed for use in power limited circuits.
- Commonly used to connect and run wiring for intercom systems.
- Works well for burglar alarms and related alarm wiring needs.
- Serves business machines that require power-limited control and signal wiring.
- Applies to cash registers for power-limited wiring connections.
- Fits control applications such as automatic valve control systems.
- Installs in irrigation systems for power-limited control wiring.
Encore Wire - C0431A.41.10 - Specifications
| Manufacturer Name | Encore Wire |
|---|---|
| Manufacturer Part Number | C0431A.41.10 |
| Conductor Count | 2 Conductor |
| Item Description | Power-Limited Tray Cable,22 AWG,2 Conductor,Stranded,Tin-Plated Copper Conductor,-20 to 105 C,300 V |
| Conductor Material | Tinned Copper |
| Conductor Size | 22 Awg |
| Conductor Stranding | 7 Strands Per Conductor |
| Conductor Type | Stranded |
| Dimensions | Od: 0.185 In. |
| Insulation Material | Pvc |
| Insulation Thickness | 0.013 In. (0.33 Mm) |
| Jacket Color | Gray |
| Jacket Material | Pvc |
| Length | 1000 Ft. |
| Product Type | Power-Limited Tray Cable |
| Shield Type | Unshielded |
| Special Rating | Csa, Ul |
| Temperature Rating | -20 To 105 C |
| Voltage | 300 V |
