Encore Wire C0432A.41.10 | Power-Limited Tray Cable, 22 AWG, 3 Conductor, Stranded, Tin-Plated Copper Conductor, -20 to 105 C, 300 V
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Encore Wire C0432A.41.10 | Power-Limited Tray Cable, 22 AWG, 3 Cond...
Description
Description
Power-Limited Tray Cable, Conductor Size: 22 AWG, Conductor Count: 3 Conductor, Conductor Type: Stranded, Conductor Material: Tin-Plated Copper, Temperature Rating: -20 to 105 C, Insulation Material: PVC, Insulation Thickness: 0.013 in., Shield Type: Unshielded, Jacket Material: PVC, Jacket Color: Black, Voltage: 300 V, Length: 1000 ft., Conductor Stranding: 7 x 30 Strand, Dimensions: OD: 0.198 in., Special Rating: CSA, UL, Additional_Details: K1
Specifications
Specifications
Encore Wire - C0432A.41.10 - Applications
- Designed for cable tray installations where NEC Type PLTC wiring is required.
- Supports power-limited circuits for control and signal wiring.
- Commonly used in intercom systems and burglar alarms.
- Suitable for business machines and cash registers in low-power system wiring.
- Used in automatic valve control systems and irrigation systems.
Encore Wire - C0432A.41.10 - Specifications
| Manufacturer Name | Encore Wire |
|---|---|
| Manufacturer Part Number | C0432A.41.10 |
| Conductor Count | 3 Conductor |
| Item Description | Power-Limited Tray Cable,22 AWG,3 Conductor,Stranded,Tin-Plated Copper Conductor,-20 to 105 C,300 V |
| Conductor Material | Tin-Plated Copper |
| Conductor Size | 22 Awg |
| Conductor Stranding | 7 X 30 Strand |
| Conductor Type | Stranded |
| Dimensions | Od: 0.198 In. |
| Insulation Color Code | White |
| Insulation Material | Pvc |
| Insulation Thickness | 0.013 In. |
| Jacket Color | Black |
| Jacket Material | Pvc |
| Length | 1000 Ft. (304.8 M) |
| Product Type | Power-Limited Tray Cable |
| Shield Type | Unshielded |
| Special Rating | Csa, Ul |
| Temperature Rating | -20° To 105°C (-4° To 221°F) |
| Voltage | 300 V |
