Encore Wire C4063A.41.10 | Multi-Conductor Cable, Green, Tinned Cop...
Description
Description
The multi-conductor array of communication and control cable facilitates cable pull-ins and single-site installations. This cable is typically used for industrial equipment control, electric valve actuation and remote signaling, as well as communications and broadcast applications. These designs are available in a wide variety of insulation and jacketing materials, as well as shield designs to alleviate unwanted circuit noise.
Specifications
Specifications
Encore Wire - C4063A.41.10 - Applications
- Public address systems commonly use it where control and signal wiring is needed.
- Intercom connections use it for signal and control circuits.
- Internal telephones use it in control and signal wiring setups.
- Remote control circuits use it where control and signal cable is required.
- EIA RS-232 applications use it.
Encore Wire - C4063A.41.10 - Specifications
| Manufacturer Name | Encore Wire |
|---|---|
| Manufacturer Part Number | C4063A.41.10 |
| Color | Green |
| Item Description | Multi-Conductor Cable, Green, Tinned Copper, Fully Annealed Stranded, Semi-Rigid PVC, Gray |
| Conductor Count | 4 Conductor |
| Conductor Material | Tinned Copper |
| Conductor Size | 22 Awg |
| Conductor Stranding | 7 Strands Per Conductor |
| Insulation Material | Pvc |
| Jacket Color | Gray |
| Jacket Material | Pvc |
| Length | 1000 Ft. |
| Product Type | Multi-Conductor Cable |
| Shield Type | Unshielded |
| Temperature Rating | -20° To 80°C (-4° To 176°F) |
| Voltage | 300 V |
