Encore Wire C4075A.41.10 | 22–20 AWG Stranded Twisted Pair RS-232 C...
Description
Description
The multi-conductor array of communication and control cable facilitates cable pull-ins and single-site installations. This cable is typically used for industrial equipment control, electric valve actuation and remote signaling, as well as communications and broadcast applications. These designs are available in a wide variety of insulation and jacketing materials, as well as shield designs to alleviate unwanted circuit noise.
Specifications
Specifications
Encore Wire - C4075A.41.10 - Applications
- Use it in public address systems where multi-conductor signal and control wiring is needed.
- Install it for intercoms that require reliable low-voltage communication wiring.
- Choose it for internal telephones in building communication systems.
- Apply it in remote control circuits for control and signaling connections.
- Specify it for EIA RS-232 applications in communication and control setups.
Encore Wire - C4075A.41.10 - Specifications
| Manufacturer Name | Encore Wire |
|---|---|
| Manufacturer Part Number | C4075A.41.10 |
| Color | Red, Green |
| Item Description | 22–20 AWG Stranded Twisted Pair RS-232 Communication Cable, PVC Jacket, Gray |
| Conductor Count | 20 Conductor |
| Conductor Material | Tinned Copper |
| Conductor Size | 22 Awg |
| Conductor Stranding | 7 Strands Per Conductor |
| Insulation Material | Pvc |
| Jacket Color | Gray |
| Jacket Material | Pvc |
| Length | 1000 Ft. |
| Product Type | Multi-Conductor Cable |
| Shield Type | Unshielded |
| Temperature Rating | -20° To 80°C (-4° To 176°F) |
| Voltage | 300 V |
