Encore Wire E2206S.41.86 | Fire Alarm Cable, 18 AWG, 6 Conductor, 7 x 26 Strand, Bare Copper Conductor, PVC Insulation
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Encore Wire E2206S.41.86 | Fire Alarm Cable, 18 AWG, 6 Conductor, 7...
Description
Description
Fire Alarm Cable, Conductor Size: 18 AWG, Conductor Count: 6 Conductor, Conductor Stranding: 7 x 26 Strand, Conductor Material: Bare Copper, Insulation Material: PVC, Insulation Thickness: 0.01 in., Shield Type: Foil Shielded, Outer Jacket Material: PVC, Outer Jacket Color: Natural, Temperature Rating: 0 to 75 C, Fire Rating: Plenum, Voltage: 300 V, Special Rating: NEC, UL, Conductor Type: Stranded, Length: 1000 ft., Outside Diameter: 0.218 in.
Specifications
Specifications
Encore Wire - E2206S.41.86 - Applications
- Supports power-limited control circuits where organized multi-conductor wiring is required.
- Commonly used for wiring intercom systems in plenum spaces.
- Works well for wiring security systems where shielded construction is desired.
- Often used for wiring audio systems to help reduce interference.
- Fits background music system wiring in low-voltage installations.
Encore Wire - E2206S.41.86 - Specifications
| Manufacturer Name | Encore Wire |
|---|---|
| Manufacturer Part Number | E2206S.41.86 |
| Conductor Count | 6 Conductor |
| Item Description | Fire Alarm Cable, 18 AWG, 6 Conductor, 7 x 26 Strand, Bare Copper Conductor, PVC Insulation |
| Conductor Material | Bare Copper |
| Conductor Size | 18 Awg |
| Conductor Stranding | 7 Strands Per Conductor |
| Conductor Type | Stranded |
| Fire Rating | Plenum |
| Insulation Material | Pvc |
| Insulation Thickness | 0.01 In. (0.25 Mm) |
| Length | 1000 Ft. |
| Outer Jacket Color | Tan |
| Outer Jacket Material | Pvc |
| Outside Diameter | 0.218 In. |
| Product Type | Fire Alarm Cable |
| Shield Type | Foil Shield |
| Special Rating | Nec, Ul |
| Temperature Rating | 0° To 75°C (32° To 167°F) |
| Voltage | 300 V |
Documents and Downloads
Documents and Downloads
