Encore Wire E3032S.41.86 | Fire Alarm Cable, 18 AWG, 2 Conductor, 7 x 26 Strand, Bare Copper Conductor, PVC Insulation
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Encore Wire E3032S.41.86 | Fire Alarm Cable, 18 AWG, 2 Conductor, 7...
Description
Description
Fire Alarm Cable, Conductor Size: 18 AWG, Conductor Count: 2 Conductor, Conductor Stranding: 7 x 26 Strand, Conductor Material: Bare Copper, Insulation Material: PVC, Insulation Thickness: 0.008 in., Shield Type: Unshielded, Outer Jacket Material: PVC, Outer Jacket Color: Natural, Temperature Rating: 0 to 75 C, Fire Rating: Plenum, Voltage: 300 V, Special Rating: NEC, UL, Conductor Type: Stranded, Length: 100 ft., Outside Diameter: 0.156 in.
Specifications
Specifications
Encore Wire - E3032S.41.86 - Applications
- Designed for power-limited control circuits where plenum-rated cable is required.
- Supports intercom systems wiring in low-voltage installations.
- Used for security systems wiring in power-limited circuit layouts.
- Works for audio systems wiring in low-voltage systems.
- Commonly installed for background music systems wiring.
Encore Wire - E3032S.41.86 - Specifications
| Manufacturer Name | Encore Wire |
|---|---|
| Manufacturer Part Number | E3032S.41.86 |
| Conductor Count | 2 Conductor |
| Item Description | Fire Alarm Cable, 18 AWG, 2 Conductor, 7 x 26 Strand, Bare Copper Conductor, PVC Insulation |
| Conductor Material | Bare Copper |
| Conductor Size | 18 Awg |
| Conductor Stranding | 7 Strands Per Conductor |
| Conductor Type | Stranded |
| Fire Rating | Plenum |
| Insulation Material | Pvc |
| Insulation Thickness | 0.008 In. (0.2 Mm) |
| Length | 100 Ft. |
| Outer Jacket Color | Tan |
| Outer Jacket Material | Pvc |
| Outside Diameter | 0.156 In. |
| Product Type | Fire Alarm Cable |
| Shield Type | Unshielded |
| Special Rating | Nec, Ul |
| Temperature Rating | 0° To 75°C (32° To 167°F) |
| Voltage | 300 V |
