Erico B102EH001 - GROUNDING - CADWELD LUG, CU, 1/4 X 2
Regular price
$200.34
Unit price
Brand: Erico
|
SKU:
9836914
Regular price
$200.34
Unit price
Description
Description
Erico B102EH001 - GROUNDING - CADWELD LUG, CU, 1/4 X 2
Features
- Provides an efficient bolting surface for grounding and power applications
- Electrolytic grade copper
- For use with nVent ERICO Cadweld type LA connections only
Specifications
Specifications
Image 1
| Click image to enlarge. |
|---|
Image 2
| Click image to enlarge. |
|---|
Specifications
| Part Number | B102EH001 |
|---|---|
| Material | Copper |
| Finish | Tinned |
| Type | NEMA® |
| Length (L) | 6" |
| Width (W) | 2" |
| Thickness (T) | 0.25" |
| A | 0.625" |
| B | 1.75" |
| Hole Size (HS) | 0.563" |
| Equivalent Conductor Size | 637 kcmil |
| Standard Packaging Quantity | 10 pc |
| UPC | 78285672175 |
