Erico DSD140M75 - GROUNDING - MODULE, DSD, 75V, 40KA
Regular price
$78.33
Unit price
Brand: Erico
|
SKU:
9826900
Regular price
$78.33
Unit price
Description
Description
Erico DSD140M75 - GROUNDING - MODULE, DSD, 75V, 40KA
Specifications
Specifications
Image 1
| Click image to enlarge. |
|---|
Image 2
| Click image to enlarge. |
|---|
Specifications
| Part Number | DSD140M75 |
|---|---|
| Nominal System Voltage (Un) | 0 - 75 VDC |
| Max Continuous Operating Voltage (Uc) | 75 VAC, 100 VDC |
| Nominal Discharge Current (In), Per Mode | 20 kA 8/20 ?s |
| Max Discharge Current (Imax), Per Mode | 40 kA 8/20 ?s |
| Voltage Protection Level (Up) | 600 V @ 20 kA |
| Frequency | 0 – 60 Hz |
| Short Circuit Current Rating (SCCR) | 25 kA |
| Technology | MOV with thermal disconnect |
| Enclosure Material | UL® 94V-0 Thermoplastic |
| Status Indication | Mechanical flag |
| Temperature | -40 to 176 °F |
| Module Width | 1 M |
| Depth (D) | 1.91" |
| Height (H) | 1.78" |
| Width (W) | 0.71" |
| Unit Weight | 0.1 lb |
| Certifications | CE |
| Standard Packaging Quantity | 1 pc |
| UPC | 78285658201 |
| EAN-13 | 8711893041538 |
Documents and Downloads
Documents and Downloads
- Rail Solutions - Expertly Engineered. Global Capabilities
- Wind Power Solutions
- Technical Note TN CR 001, Why Install Surge Protection
- Technical Note TN CR 002, The need for co-ordinated protection
- Technical Note TN CR 003, Where to install SPD's for AC powered electronic equipment
- Technical Note TN CR 006, SPDs and the Benefits of Filtering
- Technical Note TN CR 007, - What are clamping voltages, suppressed voltage ratings and let-throughs
- Technical Note TN CR 009, What national standards are applicable to SPD's
- Technical Note TN CR 010, What is an 8/20µs waveform
