Erico DSD50M745DC - GROUNDING - REPLACEMENT MODULE, 745VD
Regular price
$162.14
Unit price
Brand: Erico
|
SKU:
9830589
Regular price
$162.14
Unit price
Description
Description
Erico DSD50M745DC - GROUNDING - REPLACEMENT MODULE, 745VD
Features
- Replacement module for Surge Diverter, 50 kA DSD DC
Specifications
Specifications
| Click image to enlarge. |
|---|
Specifications
| Part Number | DSD50M745DC |
|---|---|
| Max Discharge Current (Imax) | 50 kA 8/20 ?s |
| Max Continuous Operating Voltage (Uc) | 750 VDC |
| Voltage Protection Rating (VPR) | 2,500 V @ 3 kA |
| Nominal Discharge Current (In) | 20 kA 8/20 ?s |
| Enclosure Material | UL® 94V-0 Thermoplastic |
| Temperature | -40 to 176 °F |
| Module Width | 1 M |
| Depth (D) | 1.91" |
| Height (H) | 1.78" |
| Width (W) | 0.71" |
| Unit Weight | 0.15 lb |
| Certifications | CEUR |
| Standard Packaging Quantity | 1 pc |
| UPC | 78285684775 |
