Erico HSP10K36 - GROUNDING - High Speed Data Line Protector
Regular price
$602.58
Unit price
Brand: Erico
|
SKU:
9830550
Regular price
$602.58
Unit price
Description
Description
High Speed Data Line Protector
Features
- Multi-stage protection with primary or combination primary/secondary protectors
- 10 pair protector
- Provides both L-L and L-PE protection modes for comprehensive protection
- Simple installation into Krone® LSA disconnect block
- Data Line Terminator (DLT) available where screw terminal connections are required
Specifications
Specifications
Image 1
| Click image to enlarge. |
|---|
Image 2
| Click image to enlarge. |
|---|
Specifications
| Part Number | HSP10K36 |
|---|---|
| Max Continuous Operating Voltage (Uc) | 40 VDC |
| Max Discharge Current (Imax), L+L-PE | 20 kA 8/20 ?s |
| Rated Load Current (IL) | 150 mA |
| Frequency | 12 MHz Max |
| Transmission Rate | 8 Mb/s |
| Protection Modes | L-L, L-PE |
| Technology | Multi-stage |
| Connection Type | Krone® LSA-PLUS |
| Impedance Balance | 55 dB Max |
| Insertion Loss | .4 Db Max |
| Return Loss | 20 dB Max |
| Loop Resistance | 16.4 ? |
| Temperature | -4 to 140 °F |
| Enclosure Material | UL® 94V-0 Thermoplastic |
| Depth (D) | 0.83" |
| Height (H) | 1.36" |
| Width (W) | 4.92" |
| Unit Weight | 0.05 lb |
| Certifications | CE, C-Tick, cULus |
| Standard Packaging Quantity | 1 pc |
| UPC | 78285647506 |
| EAN-13 | 8711893024678 |
Documents and Downloads
Documents and Downloads
- Rail Solutions - Expertly Engineered. Global Capabilities
- Rail Surge Protection Guide
- Surge Protection Solutions
- cUL QVGV7.E321473
- UL QVGV.E321473
- Technical Note TN CR 001, Why Install Surge Protection
- Technical Note TN CR 002, The need for co-ordinated protection
- Technical Note TN CR 003, Where to install SPD's for AC powered electronic equipment
- Technical Note TN CR 006, SPDs and the Benefits of Filtering
