Erico SGD1121SRNE - GROUNDING - Modular Spark Gap Diverter
Regular price
$274.64
Unit price
Brand: Erico
|
SKU:
9828221
Regular price
$274.64
Unit price
Description
Description
Erico SGD1121SRNE - GROUNDING - Modular Spark Gap Diverter
Features
- Effective equipotential bonding provides N-PE equalization protection bond on TT power distribution systems
Specifications
Specifications
Image 1
| Click image to enlarge. |
|---|
Image 2
| Click image to enlarge. |
|---|
Specifications
| Part Number | SGD1121SRNE |
|---|---|
| Nominal Discharge Current (In) | 20 kA 8/20 ?s |
| Max Discharge Current (Imax), Per Mode | 40 kA 8/20 ?s |
| Measured Limiting Voltage (MLV) | 2,460 VAC |
| Follow Current Extinguishing Capability @ Un | 100 A |
| Impulse Current (Iimp) | 12 kA 10/350 ?s |
| Max Operating Current | 0.5 mA |
| Frequency | 50 – 60 Hz |
| Protection Modes | N-PE |
| Short Circuit Current Rating (SCCR) | 25 kA |
| Technology | Encapsulated Spark Gap |
| Connection, Solid | #2 Max |
| Connection, Stranded | #3 Max |
| Mounting | 35 mm top hat DIN rail |
| Enclosure Material | UL® 94V-0 Thermoplastic |
| Enclosure Rating | IP 20NEMA®-1 |
| Remote Contacts | Yes |
| Temperature | -40 to 176 °F |
| Module Width | 1 M |
| Depth (D) | 2.68" |
| Height (H) | 3.54" |
| Width (W) | 0.69" |
| Unit Weight | 0.26 lb |
| Complies With | ANSI®/IEEE® C62.41.2-2002 Cat A, Cat B, Cat C; ANSI®/IEEE® C62.41.2-2002 Scenario II, Exposure 3, 100 kA 8/20 ?s, 10 kA 10/350 ?s, IEC® 61643-1 Class I, Class II |
| Replacement Module | SGD112M |
| Certifications | CE, cURus |
| Standard Packaging Quantity | 1 pc |
| UPC | 78285656772 |
| EAN-13 | 8711893041576 |
Documents and Downloads
Documents and Downloads
- Rail Solutions - Expertly Engineered. Global Capabilities
- Wind Power Solutions
- cUR VZCA8.E325047
- UR VZCA2.E325047
- Technical Note TN CR 001, Why Install Surge Protection
- Technical Note TN CR 002, The need for co-ordinated protection
- Technical Note TN CR 003, Where to install SPD's for AC powered electronic equipment
- Technical Note TN CR 006, SPDs and the Benefits of Filtering
- Technical Note TN CR 007, - What are clamping voltages, suppressed voltage ratings and let-throughs
