Erico SGT15010 - GROUNDING - Spark Gap Diverter, Type 1, 50KA
Regular price
$509.41
Unit price
Brand: Erico
|
SKU:
9826989
Regular price
$509.41
Unit price
Description
Description
Erico SGT15010 - GROUNDING - Spark Gap Diverter, Type 1, 50KA
Features
- Effective equipotential bonding provides N-PE equalization protection bond on TT power distribution systems
Specifications
Specifications
| Click image to enlarge. |
|---|
Specifications
| Part Number | SGT15010 |
|---|---|
| Nominal Discharge Current (In), IEC | 50 kA 8/20 ?s |
| Nominal Discharge Current (In), UL | 20 kA 8/20 ?s |
| Max Continuous Operating Voltage (Uc) | 305 VAC |
| Max Discharge Current (Imax), Per Mode | 100 kA 8/20 ?s |
| Impulse Current (Iimp) | 50 kA 10/350 ?s |
| Voltage Protection Level (Up) | 1,500 V |
| Response Time | 100 ns Max |
| Follow Current Interrupt Rating (Ifi) | 100 A |
| Temporary Over Voltage Withstand 200 ms (Ut), N-PE | 1,200 V |
| Voltage Protection Rating (VPR) | 1,200 V |
| Distribution System | TT (N-PE) |
| Frequency | 50 – 60 Hz |
| Protection Modes | N-PE |
| Technology | Thermal Disconnect |
| Connection, Solid | #2 Max |
| Connection, Stranded | #4 Max |
| Torque (TQ) | 39.9 in lb Max |
| Altitude | 13,123' Max |
| Humidity | 5 – 95 % RH |
| Temperature | -40 to 185 °F |
| Enclosure Material | UL® 94V-0 Thermoplastic |
| Enclosure Rating | IP 20 |
| Mounting | 35 mm DIN Rail, EN 60715 |
| Remote Contacts | No |
| Status Indication | Mechanical flag |
| Depth (D) | 2.72" |
| Height (H) | 3.54" |
| Width (W) | 0.71" |
| Unit Weight | 0.39 lb |
| Certification Details | UL® 1449 Edition 4 Type 1CA |
| Complies With | IEC® 61643-11 Class I, Class IIEN 61643-11 Type 1, Type 2 |
| Replacement Module | SGT150M |
| Certifications | CE, ERICO DT1 Series, VDE |
| Standard Packaging Quantity | 1 pc |
| UPC | 78285694794 |
| EAN-13 | 782856947943 |
