Brand: Erico
|
SKU:
9828590
Erico SGT24010R - GROUNDING - Spark Gap Diverter, Type 2, 40 KA
Regular price
$228.53
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Erico SGT24010R - GROUNDING - Spark Gap Diverter, Type 2, 40 KA
Regular price
$228.53
Unit price
Description
Description
Erico SGT24010R - GROUNDING - Spark Gap Diverter, Type 2, 40 KA
Features
- Effective equipotential bonding provides N-PE equalization protection bond on TT power distribution systems
Specifications
Specifications
| Click image to enlarge. |
|---|
Specifications
| Part Number | SGT24010R |
|---|---|
| Nominal Discharge Current (In), IEC | 40 kA 8/20 ?s |
| Nominal Discharge Current (In), UL | 20 kA 8/20 ?s |
| Max Continuous Operating Voltage (Uc) | 305 VAC |
| Max Discharge Current (Imax), Per Mode | 65 kA 8/20 ?s |
| Voltage Protection Level (Up) | 1,500 V |
| Response Time | 100 ns Max |
| Follow Current Interrupt Rating (Ifi) | 100 A |
| Temporary Over Voltage Withstand 200 ms (Ut), N-PE | 1,200 V |
| Voltage Protection Rating (VPR) | 1,200 V |
| Distribution System | TT (N-PE) |
| Frequency | 50 – 60 Hz |
| Protection Modes | N-PE |
| Technology | Thermal Disconnect |
| Connection, Solid | #2 Max |
| Connection, Stranded | #4 Max |
| Torque (TQ) | 39.9 in lb Max |
| Altitude | 13,123' Max |
| Humidity | 5 – 95 % RH |
| Temperature | -40 to 185 °F |
| Enclosure Material | UL® 94V-0 Thermoplastic |
| Enclosure Rating | IP 20 |
| Mounting | 35 mm DIN Rail, EN 60715 |
| Remote Contact Switching Capacity | 1.0 A @ 250 VAC, 0.5 A @ 48 VDC, 0.5 A @ 24 VDC, 0.5 A @ 12 VDC |
| Remote Contacts | Yes |
| Status Indication | Mechanical flag |
| Depth (D) | 3.35" |
| Height (H) | 3.54" |
| Width (W) | 0.71" |
| Unit Weight | 0.255 lb |
| Certification Details | UL® 1449 Edition 4 Type 1CA |
| Complies With | IEC® 61643-11 Class I, Class IIEN 61643-11 Type 1, Type 2 |
| Replacement Module | SGT240M |
| Standard Packaging Quantity | 1 pc |
| UPC | 78285693883 |
| EAN-13 | 782856938835 |
