Brand: Erico
|
SKU:
9825565
Erico TACY3Y3L - GROUNDING - CADWELD MOLD, CABLE, HORZ TEE
Regular price
$303.08
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Erico TACY3Y3L - GROUNDING - CADWELD MOLD, CABLE, HORZ TEE
Regular price
$303.08
Unit price
Description
Description
nVent ERICO Cadweld graphite molds are designed and engineered for thousands of connection styles and conductor combinations.
Features
- Forms a permanent, low resistance connection
- Provides a molecular bond
- nVent ERICO Cadweld Exothermic Connections are rated with the same current capacity as the conductor
- Portable installation equipment with no external source of power required
- Installers can be easily trained to make nVent ERICO Cadweld Exothermic Connections
- Connections can be visually inspected
Specifications
Specifications
| Click image to enlarge. |
|---|
Specifications
| Part Number | TACY3Y3L |
|---|---|
| Mold Family | TA |
| Conductor 1 | 50 mm² Concentric |
| Conductor 1 Outer Diameter, Nominal | 0.354" |
| Conductor 2 | 50 mm² Concentric |
| Conductor 2 Outer Diameter, Nominal | 0.354" |
| Split Crucible | Yes |
| Wear Plates | No |
| Mold Only | No |
| Welding Material | 90 or 90PLUSF20, Sold Separately |
| Handle Clamp | L160 and B265, Sold Separately |
| Frame | Not Required |
| Price Key | C |
| Ease of Use | Preferred |
| Certifications | cULus |
| Standard Packaging Quantity | 1 pc |
| UPC | 78285690589 |
| EAN-13 | 8711893147858 |
