Erico TDS130M150 - GROUNDING - TDS130 Replacement Module, 150V, 30KA
Regular price
$197.23
Unit price
Brand: Erico
|
SKU:
9826332
Regular price
$197.23
Unit price
Description
Description
Erico TDS130M150 - GROUNDING - TDS130 Replacement Module, 150V, 30KA
Features
- Replacement module for TDS130 Series
Specifications
Specifications
Image 1
| Click image to enlarge. |
|---|
Image 2
| Click image to enlarge. |
|---|
Specifications
| Part Number | TDS130M150 |
|---|---|
| Nominal System Voltage (Un) | 120 - 150 VAC |
| Max Continuous Operating Voltage (Uc) | 170 VAC |
| Voltage Protection Rating (VPR) | 800 V @ 3 kA L-N500 V @ 3 kA L+N-PE |
| Nominal Discharge Current (In) | 8 kA 8/20 ?s |
| Max Discharge Current (Imax) | 20 kA 8/20 ?s L-N20 kA 8/20 ?s L-PE |
| Frequency | 0 – 100 Hz |
| Enclosure Material | UL® 94V-0 Thermoplastic |
| Temperature | -40 to 176 °F |
| Module Width | 1 M |
| Depth (D) | 1.92" |
| Height (H) | 1.78" |
| Width (W) | 0.71" |
| Unit Weight | 0.15 lb |
| Certifications | UR |
| Standard Packaging Quantity | 1 pc |
| UPC | 78285662249 |
| EAN-13 | 8711893097160 |
Documents and Downloads
Documents and Downloads
- Rail Solutions - Expertly Engineered. Global Capabilities
- Wind Power Solutions
- UR VZCA2.E325047
- Technical Note TN CR 001, Why Install Surge Protection
- Technical Note TN CR 002, The need for co-ordinated protection
- Technical Note TN CR 003, Where to install SPD's for AC powered electronic equipment
- Technical Note TN CR 005, The Benefits of TD Technology
- Technical Note TN CR 006, SPDs and the Benefits of Filtering
- Technical Note TN CR 007, - What are clamping voltages, suppressed voltage ratings and let-throughs
