Erico TSF6A120V - GROUNDING - FILTER, SURGE, 1PH, 120V
Regular price
$517.88
Unit price
Brand: Erico
|
SKU:
9828406
Regular price
$517.88
Unit price
Description
Description
The nVent ERICO Critec Transient Surge Filter (TSF) product family is a UL registered, IEC compliant, compact, serviceable solution for protection of PLC controllers, SCADA systems, motor control centers and other process control systems.
Features
- Compact, space saving design
- Replaceable surge module reduces down time and unprotected time during maintenance
- Compliance to the latest UL 1449 Edition 4 and IEC 61643-11 surge standards and UL 1283 Electromagnetic Interference Filters (EMI) standard
- Low let-through voltages on the critical line to neutral mode
- Transient Discriminating (TD) Technology provides increased service life
Specifications
Specifications
| Click image to enlarge. |
|---|
Specifications
| Part Number | TSF6A120V |
|---|---|
| Nominal System Voltage (Un) | 120 V |
| Rated Load Current (IL) | 6 A |
| Max Continuous Operating Voltage (Uc) | 170 V |
| Stand-off Voltage | 230 |
| Frequency | 0 – 100 Hz |
| Max Discharge Current (Imax), L-N | 20 kA 8/20 ?s |
| Max Discharge Current (Imax), L-PE | 20 kA 8/20 ?s |
| Max Discharge Current (Imax), N-PE | 20 kA 8/20 ?s |
| Filtering | -65 dB @ 100 kHz |
| Distribution System | 1Ph 2W+G |
| Protection Modes | L-N, L-PE, N-PE |
| Connection, Solid | #14 – #10 |
| Connection, Stranded | #14 – #10 |
| Mounting | 35 mm top hat DIN rail |
| Status Indication | Mechanical flag, Remote Contacts |
| Enclosure Material | UL® 94V-0 Thermoplastic |
| Enclosure Rating | IP 20 |
| Temperature | -31 to 104 °F |
| Module Width | 3 M |
| Depth (D) | 3 3/4" |
| Height (H) | 4.83" |
| Width (W) | 2.13" |
| Unit Weight | 1.12 lb |
| Replacement Module | TSF120MTDS |
| Certifications | CE, ERICO TSF, cURus |
| Standard Packaging Quantity | 1 pc |
| UPC | 78285679979 |
| EAN-13 | 782856799795 |
