Erico XLVFC1TV4 - GROUNDING - CADWELD MOLD, CABLE TO VERT
Regular price
$211.81
Unit price
Brand: Erico
|
SKU:
9839616
Regular price
$211.81
Unit price
Description
Description
Developed in 1988, nVent ERICO Cadweld Exolon connections represented a significant advancement in welded electrical connections for sensitive indoor applications like data centers, hospitals, and other clean room environments. The virtual elimination of smoke and a unique electronic starting system makes this an ideal solution for sensitive applications. Each nVent ERICO Cadweld Exolon package contains ceramic filters that produce an extremely low emission connection.
Features
- Forms a permanent, low resistance connection
- Provides a molecular bond
- nVent ERICO Cadweld Exothermic Connections are rated with the same current capacity as the conductor
- Portable installation equipment with no external source of power required
- Installers can be easily trained to make nVent ERICO Cadweld Exothermic Connections
- Connections can be visually inspected
Specifications
Specifications
| Click image to enlarge. |
|---|
Specifications
| Part Number | XLVFC1TV4 |
|---|---|
| Mold Family | VF |
| Connects To | Steel Pipe |
| Conductor Size | #2 Solid |
| Conductor Outer Diameter, Nominal | 0.257" |
| Pipe Size | 4" |
| Outer Diameter | 4 1/2" |
| Split Crucible | No |
| Wear Plates | No |
| Mold Only | No |
| Welding Material | XL65, Sold Separately |
| Handle Clamp | XLL160 and B160V, Sold Separately |
| Price Key | XLC |
| Ease of Use | Preferred |
| Standard Packaging Quantity | 1 pc |
| UPC | 78285669408 |
