Fire Detection Devices Ltd CF-200 | Heat Detector, 250°F, Ceiling Mount

Fire Detection Devices Ltd CF-200 | Heat Detector, 250°F, Ceiling Mount


The model number prefix "CF" indicates that the detector is Fixed Temperature Only, and will therefore not respond to a rate of temperature increase but will operate when the detector fuses at the prescribed (Fahrenheit) temperature as indicated by the model number, i.e. 135, 165, and 200. This detector is referred to as "Fixed Temperature Only, non-restorable". The CR/CF single circuit with normally open contact configuration is available in aluminum and white finish. The suffix "W" denotes the white finish of the units. This heat detector is connected to a fire alarm system's input circuit as an initiating device. The internal contacts are normally open, and will close when the detector operates either on a rate of temperature increase, or if the releasing temperature is reached. It is often installed with an addressing module if it is to be annunciated as a specific room or space, e.g. electrical room, garbage compactor and more. With its non-metallic diaphragm, the detector can ope
