Description

The Fire Lite Alarms H365(A), H365R(A), and H365HT(A) addressable plug-in thermal detectors are designed for both performance and aesthetics and are a direct replacement for the H355 Series. A new modern, sleek, contemporary design and advanced thermal technologies make the H365(A) Series ideal for both system operation and building design.

Exclusively for use with Fire Lite?s addressable fire alarm control panels, the H365(A) Series point ID capability allows each detector?s address to be set with rotary, decimal address switches, providing exact detector location for emergency personnel to quickly locate a fire during its early stages, potentially saving precious rescue time while also reducing property damage. Two LEDs on each sensor light to provide a local, visible sensor indication.

The H365(A) Series includes fixed temperature, rate-of-rise and high heat fixed temperature detectors that provide effective, intelligent property protection for a variety of applications. Detectors are available for both LiteSpeed and CLIP applications as designated.

Key Features

LiteSpeed and CLIP
Designed to meet UL 268 7th Edition
Sleek, low-profile, stylish design
State-of-the-art thermistor technology for fast response
Integral communications and built-in device-type identification
Built-in tamper resistant feature
Built-in functional test switch activated by external magnet
Two-wire SLC loop connection
Unit uses base for wiring
Addressable by device
Rotary, decimal addressing (Refer to the Fire Lite panel manuals for device capacity.)
High-temperature model (H365HT(A)) factory preset to 190F (88C)

Specifications

Brand Name	Fire-Lite
Manufacturer	Honeywell International, Inc
Manufacturer Part Number	H365HT-IV
Product Model	H365HT-IV
Product Name	H365HT-IV Temperature Sensor
Product Type	Temperature Sensor

General Information

Name	ADDRESSABLE HEAT DET (HIGH); IV, Honeywell International, Inc, Fire-Lite
Category	Fire-lite Alarms By Honeywell, Fire, Fire Detection Devices, Thermal
UPC Code	783863051791
Country of origin	Mexico. Country of origin is subject to change.

Technical Information

Maximum Relative Humidity	0.93
Minimum Relative Humidity	0.1
Temperature Range	190F (87.8C)

Power

Input Voltage	32 V DC

Physical Characteristics

Color	Ivory
Weight (Approximate)	3.40 oz
Height	2
