Brand: Fire-Lite Alarms Inc.
|
SKU:
674633
Fire-Lite Alarms, Inc. W-MMF | Wireless Addressable Monitor Module, Honeywell International
Regular price
$390.16
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Fire-Lite Alarms, Inc. W-MMF | Wireless Addressable Monitor Module,...
Regular price
$390.16
Unit price
Brand: Fire-Lite Alarms Inc.
|
SKU:
674633
Regular price
$390.16
Unit price
Shipping calculated at checkout.
Description
Description
Specifications
Specifications
Specifications
| Brand Name | Fire-Lite |
|---|---|
| Manufacturer | Honeywell International, Inc |
| Manufacturer Part Number | W-MMF |
| Product Line | SWIFT |
| Product Model | W-MMF |
| Product Name | W-MMF Wireless Addressable Monitor Module |
| Product Type | Input Monitor Module |
General Information
| Name | Fire-Lite W-MMF Wireless Addressable Monitor Module, Honeywell International, Inc, Fire-Lite |
|---|---|
| Category | Fire-lite Alarms By Honeywell, Fire, Fire Control Panels, Fire Control Accessories |
| UPC Code | 783863045646 |
| Country of origin | Mexico. Country of origin is subject to change. |
Technical Information
| Device Supported | Alarm Communicator |
|---|
Power
| Input Voltage | 3.3 V DC |
|---|
Environmental
| Maximum Operating Temperature | 120.2F (49C) |
|---|---|
| Minimum Operating Temperature | 32F (0C) |
Physical Characteristics
| Depth | 1.5 |
|---|---|
| Height | 4.5 |
| Weight (Approximate) | 7.90 oz |
| Width | 4.5 |
Miscellaneous
| Additional Information | Standard-sized module that supervises either a Style D (Class A) or Style B (Class B) circuit of dry-contact input devices.Cascading Mesh Wireless Technology (902-928 MHz frequency).Any wireless device can be added to act as a repeater.Average Operating Current: 210?, 3.9 EOLMaximum Current Draw: 5 mA (LED only)EOL Resistance: 3.9K OhmsMaximum IDC Wiring Resistance: 10 OhmsMaximum IDC Voltage: 3.2 VoltsMaximum Average IDC Current: 5.5?Maximum Transmit RF Power: 17 dBmRadio Frequency Range: 902-928 MHzBattery Type: 4 Panasonic CR123A or 4 Duracell DL 123ABattery Life: 1 year minimum tested, 2 years expectedBattery Replacement: Upon TROUBLE BATTERY LOW display andor during annual maintenance |
|---|---|
| Compatibility | FireLite Control Panels:MS-9200UDLSMS-9600(UD)LS Addressable |
| Certifications & Standards | UL Listed: S2424FM ApprovedFCC ID: AUBWFSMMUL 864UL 268 |
| Limited Warranty | 3 Year |
