Flair Electronics PFC48Y BMS BRN | Balanced Magnetic Switch, Recessed, High Security Balanced Magnetic Switch (BMS), Brown
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Description
Description
The PFC48Y BMS High Security Magnetic Contact is a 3/4 in. recessed contact that works well in wood and steel doors where a small concealed contact is preferred. The UL Listed magnetic contact has two CC door switches and one OC magnetic tamper switch when magnet is present. There are four color coded wires and an adjustable rare earth magnet. The patented Flair recessed case locks into several gauges of steel doors as well as wood doors. Provide your customers more than just a door switch, give them time tested inexpensive Flair high security contacts with built in magnetic tamper
Flair Electronics - PFC48Y BMS BRN - Features
- 3/4" Dia. Recessed Magnetic Contact
- 12" #22 AWG Wire Leads
- Self Locking in Steel and Wood
- Balanced Magnetic Configuration with Magnetic Tamper
- Colors: White, Brown, Black and Gray
- Lifetime Warranty
- Safety Approvals
- Rare Earth Magnet
Specifications
Specifications
Flair Electronics - PFC48Y BMS BRN - Product Categories
- Security
- Intrusion Detection
- Intrusion Detection Sensors
- Contacts
Flair Electronics - PFC48Y BMS BRN - Specifications
| Manufacturer Part Number | PFC48Y BMS BRN |
|---|---|
| Manufacturer | Flair Electronics |
| Amperage | 50 |
| Color | Brown |
| Contact Configuration | High Security Balanced Magnetic Switch (BMS) |
| Diameter | 3/4 |
| Length | 0.87 |
| Loop Type | CC Door Switch; OC Magnetic Tamper |
| Material | Plastic |
| Mounting Location | Recessed Mount |
| Mounting Style | Recessed |
| Mounting | RECESSED |
| Product Type | Balanced Magnetic Switch |
| Special Rating | UL 634 |
| Standard Gap | 0 to 5/8 |
| Voltage | 100 |
| Wattage | 10 |
| Wire Size | 22 |
