Brand: Hammond Manufacturing
|
SKU:
949013
Hammond Manufacturing 125ESE | Audio Transformer, Universal Single Ended Tube Output, 15W
Regular price
$112.84
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Hammond Manufacturing 125ESE | Audio Transformer, Universal Single ...
Regular price
$112.84
Unit price
Brand: Hammond Manufacturing
|
SKU:
949013
Regular price
$112.84
Unit price
Shipping calculated at checkout.
Description
Description
Hammond Manufacturing 125ESE | Audio Transformer, Universal Single Ended Tube Output, 15W
The 125ESE is a 15W audio transformer for single-ended tube amplifier outputs. Designed for general purpose or replacement use (non-hi-fi). Frequency response: 100 Hz – 15 kHz at full rated power. For full-range audio, see the Hammond 1627–1642 Series. A versatile solution for hobbyists and amp restoration projects.
Hammond Manufacturing - 125ESE - Features
- Designed for general purpose or replacement use (not Hi-Fi), in single ended, tube output circuits.
- Frequency response: 100 Hz. - 15 Khz at full rated power (+/- 1db max. - ref. 1 Khz).
- For full frequency response (20 Hz. to 20 Khz.) - see our 1627-1642 Series .
- For push-pull output use, see our 125 Series .
- Open style with minimum 12" long primary & secondary leads.
- All sizes use butt stacked cores (using 29M6 steel) with an air gap, to reduce D.C. core saturation.
- Primary impedance range from 2,500 to 10,000 Ohms.
- Secondary impedance range from 4 to 32 Ohms.
Specifications
Specifications
Hammond Manufacturing - 125ESE - Product Categories
- Audio and Visual
- AV Cable and Connectors
- AV Cable Assemblies
- Transformers
- Audio Transformers
Hammond Manufacturing - 125ESE - Specifications
| Brand Name | Hammond Manufacturing Co |
|---|---|
| Manufacturer Number | 125ESE |
| Item Description | Audio Transformer, Universal Single Ended Tube Output, 15W |
| UNSPSC Code | 52161500 |
| Part Number | 125ESE |
| Series | Universal Single Ended Tube Output (125SE Series) |
| Shipping Weight | 3 lbs(1.36 kg) |
| UNSPSC | 39121301 |
| UPC | 623980285009 |
| REACH Compliant | Yes |
| RoHS Compliant | Yes |
| Audio Watts | 15 |
| Primary Inductance (min.) | 9.58 H |
| Primary DCR (ohms) +/- 20% | 90.6 |
| Max. D.C. Bias (ma.) | 80 |
