Description
Description
HelaCon Plus Mini Wire Connectors replace traditional twist-on wire connectors. They provide faster, easier and more reliable connection and distribution of cable and conductors in electrical installation applications. Mini connectors have a compact fo otprint and can be applied tool-free using convenient, push-in simplicity. Internal spring technology is approved for solid and stranded wires.
HelaCon Plus Mini Wire Connectors replace traditional twist-on wire connectors. They provide faster, easier and more reliable connection and distribution of cable and conductors in electrical installation applications. Mini connectors have a compact footprint and can be applied tool-free using convenient, push-in simplicity. Internal spring technology is approved for solid and stranded wires.
About HellermannTyton: HellermannTyton is a global manufacturer of cable management and identification solutions for automotive, solar, electrical, construction, industrial automation, broadband and other OEM markets. The company's integrated approach to product design, sustainability, production, quality assurance and delivery is optimized to benefit local and global customers. HellermannTyton operates in 39 countries, with North American headquarters in Milwaukee, Wisconsin.
HellermannTyton - 148-90039 - Features
- Spring technology for safe, secure and reliable connections.
- Smaller footprint fits in tight spaces.
- Low insertion force makes installation of solid or stranded copper wire fast and easy.
- Color coded for easy identification of size.
- Each port acceptsultiple wire diameters for flexible applications.
- Accepts 12-22 AWG solid wire and 14-22 AWG stranded wire.
- Spring technology for safe, secure and reliable connections.
- Smaller footprint fits in tight spaces.
- Low insertion force makes installation of solid or stranded copper wire fast and easy.
- Color coded for easy identification of size.
- Each port accepts multiple wire diameters for flexible applications.
- Accepts 12–22 AWG solid wire and 14–22 AWG stranded wire.
Specifications
Specifications
HellermannTyton - 148-90039 - Product Categories
- Hardware
- Cable Management
- Innerduct
HellermannTyton - 148-90039 - Specifications
| Brand Name | HellermannTyton |
|---|---|
| Color | Blue |
| Location | Outdoor |
| Type | Coupler |
| UNSPSC Code | 39131707 |
HellermannTyton - 148-90039 - Base Data
| Article Number | 148-90039 |
|---|---|
| Type | HCPM-5 |
| Color | Blue (BU)Clear (CL) |
| Quantity Per | box |
| Short Description | HelaCon Plus Mini, Push-In Style Wire Connector, Double Spring, 5-Port, (PC), Blue, 75/pkg |
| Global Part Name | HCPM-5-PC-BU/CL |
HellermannTyton - 148-90039 - Product Dimensions
| Length L (Imperial) | 0.65 |
|---|---|
| Length L (Metric) | 16.5 |
| Width W (Imperial) | 0.93 |
| Width W (Metric) | 23.7 |
| Height H (Imperial) | 0.3 |
| Height H (Metric) | 7.7 |
| Depth D (Imperial) | 0.65 |
| Depth D (Metric) | 16.5 |
HellermannTyton - 148-90039 - Logistic & Packaging
| Package Quantity (Imperial) | 75 |
|---|---|
| Package Quantity (Metric) | 75 |
| Customs Number | 8.54E+09 |
HellermannTyton - 148-90039 - Materials & Specifications
| Material | Polycarbonate (PC) |
|---|---|
| Material Shortcut | PC |
| Flammability | UL 94 V-0 |
| Halogen Free | Yes |
| UV Resistant (Yes/No) | No |
| Operating Temperature | -22°F to +185°F (-30°C to +85°C) |
| Reach Compliant (Article 33) | Yes |
| ROHS Compliant | Yes |
| Certification/Specification | VDE | DIN EN 60998-2-2:2005-03Intertek Semko | EN 60998-2-2:2004ENECcULusUL | ANSI/UL 486-ACE | 2006/65/ECUL | ANSI/UL 486-CNEMKO AS | EN 60998-2-2:2004UL | ANSI/UL 486-BSGS Fimko Ltd | EN 60998-2-2:2004SGS Fimko Ltd | EN 60998-2-2:201NF EN 60695-2-11 (2014)NF EN 60695-2-10 (2013) |
| UL Listed (US and Canada) | Yes |
| UL Listed (US) | Yes |
HellermannTyton - 148-90039 - Videos
| HellermannTyton 148-90039 Video URL | Click to View |
|---|
