HellermannTyton 166-90175 | Helaguard Non-Metallic Ip66 Fitting, T-...
Description
Description
T- Connectors are used to join three same diameter corrugated conduits together, and redirect cables into multiple directions. Constructed of a very durable nylon material with a high resistance to salts, oils, weak acids and solvents. Designed for eas y removal with a small screwdriver. Choose from IP66 or IP68 ingress protection rated fittings.
HelaGuard Non-Metallic T-Connectors are used to join three same diameter corrugated conduits together, and redirect cables into multiple directions. Constructed of a very durable nylon material with a high resistance to salts, oils, weak acids and solvents. Designed for easy removal with a small screwdriver. IP66 ingress protection rated fittings.
About HellermannTyton: HellermannTyton is a global manufacturer of cable management and identification solutions for automotive, solar, electrical, construction, industrial automation, broadband and other OEM markets. The company's integrated approach to product design, sustainability, production, quality assurance and delivery is optimized to benefit local and global customers. HellermannTyton operates in 39 countries, with North American headquarters in Milwaukee, Wisconsin.
HellermannTyton - 166-90175 - Features
- Used to join conduits of same diameters and route to multiple directions.
- Inspection lid facilitates cable pull through and eases installation.
- Snap-on construction reduces installation time and costs by eliminating the need to thread fittings onto conduits.
- All-around "teeth" attach firmly to conduit and deliver a high extraction force.
- Durable nylon material has high resistance to salts, oils, weak acids and solvents.
- Vibration and shock tested to EN61373 Category 2.
- IP66 fitting has one-piecconstruction.
- IP68 fitting has additional conduit seal for increased protection against wind, dirt and water.
- Assists with installation by easily cutting through HelaGuard non-mettalic conduit and tubing.
Specifications
Specifications
HellermannTyton - 166-90175 - Product Categories
- Hardware
- Cable Management
- Innerduct
- Routing, Protection and Insulation
- Flexible Conduit and Fittings
- Non-Metallic Fittings
HellermannTyton - 166-90175 - Specifications
| Brand Name | HellermannTyton |
|---|---|
| Color | Black |
| Construction | Corrugated |
| Diameter | 0.75" |
| Location | Outdoor |
| Type | Coupler |
| UNSPSC Code | 39131708 |
HellermannTyton - 166-90175 - Base Data
| Article Number | 166-90175 |
|---|---|
| Type | HG075-T |
| Color | Black (BK) |
| Quantity Per | bag |
| Short Description | HelaGuard Non-Metallic IP66 Fitting, T-Connector, 0.75" Dia, PA66, Black, 3/pkg |
| Global Part Name | HG075-T-PA66-BK |
HellermannTyton - 166-90175 - Product Dimensions
| Length L (Imperial) | 3.42 |
|---|---|
| Length L (Metric) | 86.87 |
| Variant | T-Connector |
| Outside Diameter OD (Imperial) | 4.92 |
| Outside Diameter OD (Metric) | 125 |
| Nominal Diameter (Imperial) | 0.75 |
| Nominal Diameter (Metric) | 28 |
HellermannTyton - 166-90175 - Logistic & Packaging
| Package Quantity (Imperial) | 3 |
|---|---|
| Package Quantity (Metric) | 3 |
| Customs Number | 3.93E+09 |
HellermannTyton - 166-90175 - Materials & Specifications
| Material | Polyamide 6.6 (PA66) |
|---|---|
| Material Shortcut | PA66 |
| Flammability | UL 94 V-2 |
| Halogen Free | Yes |
| UV Resistant (Yes/No) | No |
| Operating Temperature | -58°F to +275°F (-50°C to +135°C) |
| Reach Compliant (Article 33) | Yes |
| ROHS Compliant | Yes |
| UL Recognized (US) | Yes |
| UL Recognized (US and Canada) | Yes |
