HellermannTyton 166-90232 | HelaGuard Non-Metallic IP66 Fitting, Co...
Description
Description
Used to join two same diameter corrugated conduits together, couplers feature a snap-on design for a quick, secure connection. Designed for easy removal with a small screwdriver. Suitable for use on all types of corrugated conduits, both fine and cours e pitch material.
HelaGuard Non-Metallic Conduit Coupler is used to join two same diameter corrugated conduits together. Couplers feature a snap-on design for a quick, secure connection. Designed for easy removal with a small screwdriver. Suitable for use on all types of corrugated conduits, both fine and course pitch material. IP66 ingress protection rated fittings.
About HellermannTyton: HellermannTyton is a global manufacturer of cable management and identification solutions for automotive, solar, electrical, construction, industrial automation, broadband and other OEM markets. The company's integrated approach to product design, sustainability, production, quality assurance and delivery is optimized to benefit local and global customers. HellermannTyton operates in 39 countries, with North American headquarters in Milwaukee, Wisconsin.
HellermannTyton - 166-90232 - Features
- One-piece fitting used to join conduits of same diameters.
- Snap-on construction reduces installation time and costs by eliminating the need to thread fittings onto conduits.
- All-around "teeth" attach firmly to conduit and deliver a high extraction force.
- Durable nylon material has high resistance to salts, oils, weak acids and solvents.
- IP66 ingress protection rating against water, dust and wind.
- Very high impact strength; recovers completely if crushed and provides excellent fatigue life.
- Highly UV resistant; suitable for use in outdoor applications.
- Offered in fine or course corrugated pitch.
- Offered with or without slit; slit options offer easy access during installation and maintenance.
Specifications
Specifications
HellermannTyton - 166-90232 - Product Categories
- Hardware
- Cable Management
- Innerduct
- Routing, Protection and Insulation
- Flexible Conduit and Fittings
- Non-Metallic Fittings
HellermannTyton - 166-90232 - Specifications
| Brand Name | HellermannTyton |
|---|---|
| Color | Black |
| Construction | Corrugated |
| Diameter | 0.75" |
| Location | Outdoor |
| Type | Coupler |
| UNSPSC Code | 39131708 |
HellermannTyton - 166-90232 - Base Data
| Article Number | 166-90232 |
|---|---|
| Type | HG075-HG075 |
| Color | Black (BK) |
| Quantity Per | bag |
| Short Description | HelaGuard Non-Metallic IP66 Conduit Coupler, 0.75" to 0.75" Dia, PA66, Black, 10/pkg |
| Global Part Name | HG075-HG075-PA66-BK |
HellermannTyton - 166-90232 - Product Dimensions
| Length L (Imperial) | 3.19 |
|---|---|
| Length L (Metric) | 81 |
| Variant | Coupler |
| Outside Diameter OD (Imperial) | 1.73 |
| Outside Diameter OD (Metric) | 44 |
| Nominal Diameter (Imperial) | 0.75 |
| Nominal Diameter (Metric) | 28 |
HellermannTyton - 166-90232 - Logistic & Packaging
| Package Quantity (Imperial) | 10 |
|---|---|
| Package Quantity (Metric) | 10 |
| Customs Number | 3.93E+09 |
HellermannTyton - 166-90232 - Materials & Specifications
| Material | Polyamide 6.6 (PA66) |
|---|---|
| Material Shortcut | PA66 |
| Flammability | UL 94 V-2 |
| Halogen Free | Yes |
| UV Resistant (Yes/No) | No |
| Operating Temperature | -58°F to +275°F (-50°C to +135°C) |
| Reach Compliant (Article 33) | No |
| ROHS Compliant | Yes |
| UL Recognized (US) | Yes |
| UL Recognized (US and Canada) | Yes |
