HellermannTyton 166-90321 | HelaGuard Non-Metallic IP66 Fitting, Straight, M20 Thread, 0.38" Dia, PA66, Black, 10/pkg
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
HellermannTyton 166-90321 | HelaGuard Non-Metallic IP66 Fitting, St...
Description
Description
Straight fitting features a snap-on design that provides a quick, secure connection. Constructed of a very durable nylon material with a high resistance to salts, oils, weak acids and solvents. Designed for easy removal with a small screwdriver. IP66 i ngress protection rated fittings.
HelaGuard Non-Metallic Straight fitting features a snap-on design that provides a quick, secure connection. Constructed of a very durable nylon material with a high resistance to salts, oils, weak acids and solvents. Designed for easy removal with a small screwdriver. IP66 ingress protection rated fittings.
About HellermannTyton: HellermannTyton is a global manufacturer of cable management and identification solutions for automotive, solar, electrical, construction, industrial automation, broadband and other OEM markets. The company's integrated approach to product design, sustainability, production, quality assurance and delivery is optimized to benefit local and global customers. HellermannTyton operates in 39 countries, with North American headquarters in Milwaukee, Wisconsin.
HellermannTyton - 166-90321 - Features
- External NPT thread provides a secure connection.
- Snap-on construction reduces installation time and costs by eliminating the need to thread fittings onto conduits.
- All-around "teeth" attach firmly to conduit and deliver a high extraction force.
- Durabe nylon material has high resistance to salts, oils, weak acids and solvents.
- IP66 fitting has one-piece construction.
- Integrated design allows for easy insertion by hand.
- 1–3mm panel thickness range allows for multiple applications.
- Double-compression design can accommodate up to 2 wires or cables of varying sizes.
- Presents a high extraction force for withstanding extreme conditions.
Specifications
Specifications
HellermannTyton - 166-90321 - Product Categories
- Hardware
- Cable Management
- Innerduct
- Routing, Protection and Insulation
- Flexible Conduit and Fittings
- Non-Metallic Fittings
HellermannTyton - 166-90321 - Specifications
| Brand Name | HellermannTyton |
|---|---|
| Color | Black |
| Location | Outdoor |
| Type | Coupler |
| UNSPSC Code | 39131708 |
HellermannTyton - 166-90321 - Base Data
| Article Number | 166-90321 |
|---|---|
| Type | HG038-S-M20 |
| Color | Black (BK) |
| Quantity Per | bag |
| Short Description | HelaGuard Non-Metallic IP66 Fitting, Straight, M20 Thread, 0.38" Dia, PA66, Black, 10/pkg |
| Global Part Name | HG038-S-M20-PA66-BK |
HellermannTyton - 166-90321 - Product Dimensions
| Length L (Imperial) | 1.73 |
|---|---|
| Length L (Metric) | 44 |
HellermannTyton - 166-90321 - Logistic & Packaging
| Package Quantity (Imperial) | 10 |
|---|---|
| Package Quantity (Metric) | 10 |
| Customs Number | 3.93E+09 |
HellermannTyton - 166-90321 - Materials & Specifications
| Material | Polyamide 6.6 (PA66) |
|---|---|
| Material Shortcut | PA66 |
| UV Resistant (Yes/No) | No |
| Operating Temperature | -58°F to +275°F (-50°C to +135°C) |
| Reach Compliant (Article 33) | No |
| ROHS Compliant | Yes |
