HellermannTyton 170-03165 | Nomex High Temperature Woven Sleeving, ...
Description
Description
A densely woven aramid fiber sleeving, this soft and flexible material is self extinguishing and can withstand temperatures reaching up to 662F. Excellent for use in extremely harsh environments including those with exposure to direct flame, high temp eratures, as well as Beta, Gamma and X-Ray radiation - in particular, military and aerospace wiring and harnessing applications.
A densely woven aramid fiber sleeving, this soft and flexible material is self extinguishing and can withstand temperatures reaching up to 662°F. Excellent for use in extremely harsh environments including those with exposure to direct flame, high temperatures, as well as Beta, Gamma and X-Ray radiation - in particular, military and aerospace wiring and harnessing applications.
About HellermannTyton: HellermannTyton is a global manufacturer of cable management and identification solutions for automotive, solar, electrical, construction, industrial automation, broadband and other OEM markets. The company's integrated approach to product design, sustainability, production, quality assurance and delivery is optimized to benefit local and global customers. HellermannTyton operates in 39 countries, with North American headquarters in Milwaukee, Wisconsin.
HellermannTyton - 170-03165 - Features
- Self extinguishing material does not melt and is unaffected by most acids, and provides excellent thermal stability against direct flame.
- Provides excellent thermal stability.
- Meets FMVSS 302 specifications for use in automotive engineering.
- Material uts with ordinary scissors which reduces assembly time.
- Provides fuller coverage and a medium-to-high abrasion resistance.
- Expands for ease of installation in either the shop or the field.
- Increased braid density coverage provides higher level of abrasion resistance without losing flexibility.
- Contains white tracer thread for simple identification of flame retardancy.
- Treated yarns extinguish quickly and reduces potential flame spread to surrounding components.
- Cuts with ordinary scissors without fraying ends.
Specifications
Specifications
HellermannTyton - 170-03165 - Product Categories
- Hardware
- Cable Management
- Tubing
- Routing, Protection and Insulation
- Braided Sleeving - General Purpose
- Braided Sleeving - High Temperature
HellermannTyton - 170-03165 - Specifications
| Brand Name | HellermannTyton |
|---|---|
| Decimal | 1.75 Inch |
| Dual | No |
| Heat Shrink | No Is Not Shrink Tubing |
| Mil Spec | No |
| Size By Inch Fractions | 1 1/2 Inch |
| Sleeving | Yes |
| Spiral Wrap | No |
| Ul | No |
| Zipper | No |
| UNSPSC Code | 39131602 |
HellermannTyton - 170-03165 - Base Data
| Article Number | 170-03165 |
|---|---|
| Type | BSNMX1125B |
| Color | Green (GN) |
| Quantity Per | reel |
| Short Description | Nomex High Temperature Woven Sleeving, 1.5" Dia, Green, 100 ft/bulk reel |
| Global Part Name | BSNMX1125B-PMPI-GN |
HellermannTyton - 170-03165 - Product Dimensions
| Length L (Imperial) | 100 |
|---|---|
| Length L (Metric) | 30.48 |
| Bundle Diameter Min (Imperial) | 1.25 |
| Bundle Diameter Min (Metric) | 31.8 |
| Bundle Diameter Max (Imperial) | 1.75 |
| Bundle Diameter Max (Metric) | 44.4 |
| Diameter D (Imperial) | 1.5 |
| Diameter D (Metric) | 38.1 |
| Nominal Diameter (Imperial) | 1.5 |
| Nominal Diameter (Metric) | 38.1 |
HellermannTyton - 170-03165 - Logistic & Packaging
| Package Quantity (Imperial) | 100 |
|---|---|
| Package Quantity (Metric) | 30.48 |
| Customs Number | 5.81E+09 |
HellermannTyton - 170-03165 - Materials & Specifications
| Material | Polyaramid Polymetaphenylene Isophthalamide (PMPI) |
|---|---|
| Material Shortcut | PMPI |
| Flammability | UL VW-1 |
| Halogen Free | Yes |
| UV Resistant (Yes/No) | No |
| Operating Temperature | -320°F to +662°F (-196 °C to +350 °C) |
| Reach Compliant (Article 33) | Yes |
| ROHS Compliant | Yes |
