HellermannTyton LTP32-M32-CUL | HelaGuard Liquid-Tight Flexible Met...
Description
Description
Multipart straight compresssion fitting with fixed external NPT or Metric threads for liquid-tight performance. Metric threaded fittings supplied with insulated throat which protects conductors from mechanical damage caused by vibration. Constructed wi th nickel plated brass components that resists corrosion, ensures high mechanical strength and electrical continuity. UL Listed and suitable for hazardous locations as defined by NEC Article 501. Fitting comprised of body, nut, grounding ferrule and ny lon compression seal. For use with LTP series liquid tight metallic conduit.
About HellermannTyton: HellermannTyton is a global manufacturer of cable management and identification solutions for automotive, solar, electrical, construction, industrial automation, broadband and other OEM markets. The company's integrated approach to product design, sustainability, production, quality assurance and delivery is optimized to benefit local and global customers. HellermannTyton operates in 39 countries, with North American headquarters in Milwaukee, Wisconsin.
HellermannTyton - LTP32-M32-CUL - Features
- UL Listed to UL514B standards.
- Multipart compression fitting includes nylon seal for ingress protection ratings to IP66 + IP67 + IP68 + IP69
- Durable nickel plated brass material provides high mechanical strength and resistance to oil & corrosion.
- Suitble for knockouts or NPT / Metric threaded entries
- Interchangeable with all LTP series liquid-tight metallic conduits made to UL360 sizes
- Suitable for use in hazardous locations as per NEC Article 501 (B)(2): Class I, Division 2; Article 502 (A)(2) & (B)(2) Class II, Division 1 and 2; and Article 503 (A)(3) & (B)(3) Class III, Divisions 1 and 2.
- UL Listed to UL514B standards.
- Multi-part compression fitting include nylon seal for ingress protection ratings to IP66 + IP67 + IP68 + IP69.
- Durable Nickel Plated Brass material provides high mechanical strength and resistance to oil & corrosion.
- Suitable for knockouts or Metric threaded entries.
- Interchangeable with all LTP series liquid-tight metallic conduits made to UL360 sizes.
- Suitable for use in hazardous locations as per NEC Article 501 (B)(2): Class I, Division 2; Article 502 (A)(2) & (B)(2) Class II, Division 1 and 2; and Article 503 (A)(3) & (B)(3) Class III, Divisions 1 and 2.
Specifications
Specifications
HellermannTyton - LTP32-M32-CUL - Product Categories
- Hardware
- Cable Management
- Innerduct
HellermannTyton - LTP32-M32-CUL - Specifications
| Brand Name | HellermannTyton |
|---|---|
| Diameter | 1" |
| Location | Indoor |
| Type | Accessory |
| UNSPSC Code | 39121311 |
