Hid - Usa 940NTPTEKE01A3 | iCLASS SE R90, Contactless Smart Card Re...
Description
Description
iCLASS SE R90 is part of HID Global's iCLASS SE platform for adaptable, interoperable access control. Designed for vehicle access applications requiring extended read range, iCLASS SE R90 supports a broad array of credential technologies and a variety of form factors, including cards and fobs.
With a focus on sustainability, iCLASS SE platform readers include intelligent power management that reduces power consumption by as much as 59%. Selected models also have Environmental Product Declaration certification and Green Circle certification, which contributes toward LEED building credits.
Hid - Usa - 940NTPTEKE01A3 - Features
- Adaptable – Interoperable with a growing range of technologies (iCLASS Seos® , iCLASS SE, iCLASS®, MIFARE Classic, MIFARE DESFire EV1) and form factors.
- Powerfully Secure – The iCLASS SE platform’s Secure Identity Object® (SIO®) data model provides an extra layer of encryption for additional protection of identity data
- Standardized Communications (OSDP) – Uses Open Supervised Device Protocol (OSDP) for secure communications between reader and controller.
Specifications
Specifications
Hid - Usa - 940NTPTEKE01A3 - Specifications
| Typical Read Range | iCLASS Seos: 4.7" (12 cm), iCLASS: 14.2" (36 cm) |
|---|---|
| Mounting | Metal gooseneck pedestal, without a metal back plate |
| Color | Black |
| Dimensions | 13.1" x 13.1" x 1.55" (33.3cm x 33.3cm x 3.9cm) |
| Keypad | No |
| Product Weight (Terminal Strip) | 4lb 1oz (1844g) |
| Operating Voltage Range | 12 VDC or 24 VDC |
| Current Draw - Standard Power Mode (mA) | 110 @ 12V |
| Current Draw - Intelligent Power Management (IPM) Mode (mA) | 30 @ 12V |
| Peak Current Draw - Standard Power or IPM Mode (mA) | 300 @ 12V |
| NSC Power Consumption - Standard Power Mode | 1.3 @ 12V |
| NSC Power Consumption - w/ IPM | 0.4 @ 12V |
| Operating Temperature | -31º to 150º F (-35º to 65º C) |
| Storage Temperature | -67º to 185º F (-55º to 85º C) |
| Operating Humidity | 5% to 95% relative humidity non-condensing |
| Environmental Rating | IP65 |
| Transmit Frequency | 13.56 MHz |
| Communications | Wiegand, Clock-and-Data, Open Supervised Device Protocol (OSPD) via RS485 |
| Panel Connection | Reader Management |
| HID Reader Manager Mobile App for HID Mobile Access / OSDP infield upgrade, configuration, firmware upgrade and diagnostics | UL Ref Number |
| R90E | Warranty |
