Hoffman A1008NFAL | Aluminum Clamp-Cover Type 4X, 10x8x4
Description
Description
The Clamp-Cover Aluminum Enclosure is a lightweight enclosure solution that features a removable cover that secures on all sides via stainless steel clamps and screws. This enclosure is ideal for protecting components and controls in either corrosive indoor or outdoor environments, and maintains a Type-4X rating.
Purchase panels separately
Optional aluminum panels are unpainted, or steel panels are painted white; conductive and stainless panels are also available for most sizes.
Main Features
- Aluminum enclosure
- Seams continuously welded and ground smooth
- Stainless steel screws and clamps on four sides of cover
- Oil-resistant gasket
- Weldnuts provided for mounting optional panels
- Enclosures are unpainted, with covers and sides of body having a smooth, brushed finish
Specifications
Specifications
Industry Standards
- UL 50, 50E Listed; Type 3R, 4, 4X, 12; File No. E27525
- cUL Listed per CSA C22.2 No 94; Type 3R, 4, 4X, 12; File No. E27525
- UL 508A Listed; Type 3R, 4, 4X, 12; File No. E61997
- cUL Listed per CSA C22.2 No 94; Type 3R, 4, 4X, 12; File No. E61997
- NEMA/EEMAC Type 3R, 4, 4X, 12, 13
- CSA File No. 42184: Type 4, 4X, 12
- IEC 60529, IP66
- Meets NEMA Type 3RX requirements
Related Accessories
- Catalog #: A10P8
- Catalog #: A10P8AL
- Catalog #: A10P8C
- Catalog #: A10P8G
- Catalog #: A10P8SS
- Catalog #: AL23SS
- Catalog #: APLKJIC6SS
- Catalog #: AL18
Specifications
| Height | 10 in / 254 mm |
|---|---|
| Width | 8 in / 203 mm |
| Depth | 4 in / 102 mm |
| Protection Rating | NEMA Type 12; NEMA Type 13; NEMA Type 4; NEMA Type 4X; NEMA Type 3R; IP66 |
| Material | Aluminum |
| Panel Size | 8.75 x 6.88 in / 222 x 175 mm |
| Conductive Panel | A10P8G |
| Overall Dimensions | 11.50 x 9.38 in / 292 x 238 mm |
| Aluminum Panel | A10P8AL |
| Steel Panel | A10P8 |
| Mounting | 10.75 x 6.00 in / 273 x 152 mm |
| Color | Unpainted |
| BULLETIN NUMBER | A51A |
