Brand: Hoffman
|
SKU:
649364
Hoffman A36D3012 | NEMA Type 9, 36.00x30.00x12.00, Gray, Steel
Regular price
$15,129.95
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Hoffman A36D3012 | NEMA Type 9, 36.00x30.00x12.00, Gray, Steel
Regular price
$15,129.95
Unit price
Description
Description
For use in Class II Division 1 and 2 locations as defined in Article 500 of the National Electrical Code as having the presence of combustible dusts.
Note: Class II enclosures must have minimum of 3.50 full threads at all conduit entrances. NEMA requires conduit entrances to be in top and/or bottom of enclosure. Tapped holes for conduit should have tapered pipe threads.
Main Features
- Ends are .38-in. (10-mm) steel plate to provide a minimum of 3.50 full threads for conduit sizes through 2.00 in. (51 mm)
- Covers are .25-in. (6-mm) thick to allow mounting of NEMA 9 pushbuttons and pilot lights, which require threaded holes (3/4-14 NPSM thread)
- Heavy duty cover hinges on enclosures when "A" is 20.00 in. (508 mm) or more
- Fiber gasket, mechanically attached to cover, assures dust-tight enclosure
- Weldnuts or collar studs provided for mounting optional panel
Specifications
Specifications
Industry Standards
- UL Class II Division 1 and 2 Group E, F and G locations
- UL File No. E67456
- NEMA/EEMAC Type 9
- CSA certified for Class II Division 1 and 2 Group E, F and G locations
- IEC 60529, IP60
- CSA File No. 42186
Specifications
| Height | 36 in / 914 mm |
|---|---|
| Width | 30 in / 762 mm |
| Depth | 12 in / 305 mm |
| Protection Rating | NEMA Type 9 |
| Material | Mild Steel |
| Panel Size | 33.00 x 27.00 in / 838 x 686 mm |
| Overall Dimensions | 38.50 x 32.88 in / 978 x 835 mm |
| Mounting | 30.75 x 31.62 in / 781 x 803 mm |
| Panel | A36P30 |
| Mounting Hole Quanity | 6 |
| Body Thickness | 0.19 in / 4.8 mm |
| Color | Gray |
| BULLETIN NUMBER | A9 |
