Brand: Hoffman
|
SKU:
650352
Hoffman A86M4E20LP | Free-Stand, Multi-Door, Type 12, 86.12x149.19x20.12, Steel LP
Regular price
$22,250.43
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Hoffman A86M4E20LP | Free-Stand, Multi-Door, Type 12, 86.12x149.19x...
Regular price
$22,250.43
Unit price
Description
Description
Enclosures are available with three, four or five doors for housing larger control systems in industrial environments where mechanical interlock is required
Order panels separately.
Features and Benefits
- Seams continuously welded and ground smooth; no holes or knockouts
- Heavy steel back stiffeners maintain flatness and increase rigidity
- Heavy-duty lifting eyes anchored into reinforced top
- Overlapping, gasketed openings on two-door centerposts
- At two-door openings, gasketed overlapping doors eliminate need for centerposts
- Three-point latches operated by padlocking handle
- Concealed, easy-to-remove hinges
- Mechanical interlock standard on each enclosure with right-hand door serving as master door; doors can be closed in any order
- Large data pocket is high-impact thermoplastic
- Oil-resistant door gasket
- Panel mounting studs
- Bonding provision on doors
- Provisions for mounting fluorescent lights
Specifications
Specifications
Industry Standards
- UL 508A Listed; Type 12; File No. E61997
- cUL Listed per CSA C22.2 No 94; Type 12; File No. E61997
- NEMA/EEMAC Type 12
- CSA, File No. 42186, Type 12
- IEC 60529, IP55
Related Accessories
- Catalog #: AS050
- Catalog #: G280416G050
Specifications
| Height | 86.12 in / 2187 mm |
|---|---|
| Width | 149.19 in / 3789 mm |
| Depth | 20.12 in / 511 mm |
| Protection Rating | NEMA Type 12; IP55 |
| Material | Mild Steel |
| Door Quantity | 4 |
| Lifting Eye Quantity | 8 |
| Color | Gray |
| Color Code | ANSI 61 |
| Finish | Powder Coated |
| Thickness | 11 ga / 3.04 mm |
| Weight | 1802 lb |
| BULLETIN NUMBER | A27 |
Documents and Downloads
Documents and Downloads
- Hoffman A86M4E20LP Data Sheet
- Hoffman A86M4E20LP Declaration of Compliance
- Hoffman A86M4E20LP Declaration of Conformity, CSA Type 12
- Hoffman A86M4E20LP CE-00019
- Hoffman A86M4E20LP Lockwasher and Hub Installation Instruction Manual
- Hoffman A86M4E20LP Single-Sided Shelf Repainting Instructions
- Hoffman A86M4E20LP Grounding Kit Instruction Manual
- Hoffman A86M4E20LP Large Enclosure Handling Instructions
