Brand: Hoffman
|
SKU:
650819
Hoffman ANADFK | Swing-Out Panel Kit for Wall-Mount Enclosure, 4.00x2.56x1.42, Zinc Plated, Steel
Regular price
$194.54
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Hoffman ANADFK | Swing-Out Panel Kit for Wall-Mount Enclosure, 4.00...
Regular price
$194.54
Unit price
Description
Description
Swing-Out Panel Kits allow mounting standard junction box and NEMA style panels (purchase separately) near the front of the enclosure for easy access to or reading of gauges, switches, pilot lights and other components. Kit consist of heavy-gauge brackets and hinges which are easily installed by drilling small holes in the sides of the enclosure and bolting the brackets in place.
Main Features
- External screws are stainless steel
- internal components are plated steel
- All mounting hardware and instructions are provided
- Both Kits maintain UL Type 4 rating when properly installed in a Hoffman enclosure
- Swing-Out Panel Kits do not fit single-door disconnect enclosures
Specifications
Specifications
Specifications
| Height | 4 in / 102 mm |
|---|---|
| Width | 2.56 in / 65 mm |
| Depth | 1.42 in / 36 mm |
| Material | Mild Steel |
| Finish | Zinc Plated |
| Color | Unpainted |
| Thickness | 16 ga / 1.52 mm |
| Max Load | 100 lb / 45.4 kg |
| Use In | One-door Type 4, 4X, 12 and 13 enclosures where A x B is 12.00 x 12.00 in. (305 x 305 mm) or larger - HCLO Type 3R enclosures where A x B is 16.00 x 16.00 in. (406 x 406 mm) or larger - HCR Type 3R enclosures where A x B is 16.00 x 12.00 (406 x 305 mm) or larger - Type 1 enclosures where A x B is 42.00 x 30.00 in. (1067 x 762 mm) or larger |
| Weight | 2.4 lb |
| BULLETIN NUMBER | A80 |
