Brand: Hoffman
|
SKU:
509259
Hoffman CCA16169 | Aluminum Compact, Type 4X, 160x160x90mm
Regular price
$306.92
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Hoffman CCA16169 | Aluminum Compact, Type 4X, 160x160x90mm
Regular price
$306.92
Unit price
Description
Description
For use in indoor or outdoor applications, these enclosures protect components and controls in corrosive environments.
A x B x C are internal dimensions.
Purchase panels separately
CCA886, CCA1286 and CCA1886 enclosures have only two mounting holes.
Main Features
- Cast Aluminum material
- No welded seams or sharp corners
- Stainless steel captivated cover screws placed outside sealed area
- Two to four grounding screws located on enclosure back wall
- Oil-resistant, seamless foam-in-place gasket
- Tongue-and-groove sealing construction
- Threaded internal bosses provided for mounting optional panels, rails and other components
- Mounting holes provided in corners outside of gasketed area
Specifications
Specifications
Industry Standards
- UL 508A Listed; Type 4, 4X, 12, 13; File No. E61997
- NEMA/EEMAC Type 4, 4X, 12, 13
- CSA File No. 42186: Type 4, 4X, 12, 13
- IEC 60529, IP66
Related Accessories
- Catalog #: AS050
Specifications
| Height | 6.3 in / 160 mm |
|---|---|
| Width | 6.3 in / 160 mm |
| Depth | 3.54 in / 90 mm |
| Protection Rating | NEMA Type 12; NEMA Type 13; NEMA Type 4; NEMA Type 4X; IP66 |
| Material | Aluminum |
| External Dimensions | 160 x 160 mm / 6.30 x 6.30 in |
| Conductive Panel | CCAP1616 |
| Panel Size | 146 x 146 mm / 5.75 x 5.75 in |
| Mounting | 110 x 140 mm / 4.33 x 5.51 in |
| Color | Traffic Gray |
| Color Code | RAL 7042 |
| Finish | Powder Coated |
| BULLETIN NUMBER | CA1 |
