Hoffman E1PBSS | Pushbutton Screw Cover Type 4X, 1PB x 30.5mm, SS 304
Regular price
$461.54
Unit price
Brand: Hoffman
|
SKU:
651952
Regular price
$461.54
Unit price
Description
Description
Punched specifically to house either 30.5-mm or 22.5-mm oil-tight pushbuttons, switches and pilot lights. Enclosures provide protection against dirt, dust, oil and water. See Mild Steel chapter for related mild steel enclosures.
Main Features
- Prepunched 30.5mm or 22.5mm holes
- Seams continuously welded and ground smooth
- Captivated cover screws thread into sealed wells
- Bonding provision on door; grounding nut on body
- 4-way pushbutton holes accept all brands of oil-tight pushbuttons, switches and pilot lights
- Enclosures with more than one column of pushbutton holes have internal detachable hinge to hold cover open during wiring, yet permit immediate removal
- Oil-resistant gasket
Specifications
Specifications
Hoffman On Demand Alternatives
- Catalog #: E3PBSS
- Catalog #: E2PBSS
- Catalog #: E1PBSS
- Catalog #: E1PBGSS
Specifications
| Height | 3.5 in / 89 mm |
|---|---|
| Width | 4.25 in / 108 mm |
| Depth | 2.75 in / 70 mm |
| Protection Rating | NEMA Type 12; NEMA Type 13; NEMA Type 4X; IP66 |
| Material | Stainless Steel 304 |
| Hole Quantity | 1 |
| Overall Dimensions | 4.50 x 3.47 in / 114 x 88 mm |
| Mounting | 4.00 x 2.38 in / 102 x 60 mm |
| Stainless Steel Type | Type 304 |
| Hole Size | 30.5 mm mm |
| Color | Unpainted |
| Finish | Brushed #4 |
| BULLETIN NUMBER | PB1S |
