Hoffman E2PBXSS | Extra-Deep Pushbutton Screw Cover Type 4X, 2PB x ...
Regular price
$678.99
Unit price
Brand: Hoffman
|
SKU:
651974
Regular price
$678.99
Unit price
Description
Description
Designed to house 30.5-mm oil-tight pushbuttons, switches and pilot lights. Enclosures provide protection against dirt, dust, oil and water. Extra-deep design accommodates additional contact blocks for pushbuttons. See Mild Steel chapter for related mild steel enclosures.
Main Features
- Extra-deep design accommodates additional contact blocks for pushbuttons.
- Seams continuously welded and ground smooth
- Captivated cover screws thread into sealed wells
- Bonding provision on door; grounding nut on body
- 4-way pushbutton holes accept all brands of oil-tight pushbuttons, switches and pilot lights
- Enclosures 6.00 x 4.00 x 4.75 in. (152 x 102 x 121 mm) and larger have internal detachable hinge to hold cover open during wiring, yet permit immediate removal
- Oil-resistant gasket
Specifications
Specifications
Industry Standards
- UL 508A Listed; Type 4, 4X, 12; File Number E61997
- cUL Listed per CSA C22.2 No 94; Type 4, 4X, 12; File Number E61997
- NEMA/EEMAC Type 4X, 12, 13
- CSA File Number 42186: Type 4, 4X, 12
- IEC 60529, IP66
Hoffman On Demand Alternatives
- Catalog #: E1PBXSS
Specifications
| Height | 6 in / 152 mm |
|---|---|
| Width | 4 in / 102 mm |
| Depth | 4.75 in / 121 mm |
| Protection Rating | NEMA Type 12; NEMA Type 13; NEMA Type 4X; IP66 |
| Material | Stainless Steel 304 |
| Hole Quantity | 2 |
| Overall Dimensions | 7.00 x 4.22 in / 178 x 107 mm |
| Mounting | 6.50 x 3.12 in / 165 x 79 mm |
| Stainless Steel Type | 304 |
| Color | Unpainted |
| Finish | Brushed #4 |
| Thickness | 14 ga / 1.9 mm |
| BULLETIN NUMBER | PB1S |
