Hoffman E4PBGXM | Deep Pushbutton Enclosures, Type 12, 4PB x 22.5mm, Gray, Steel
Regular price
$244.13
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Hoffman E4PBGXM | Deep Pushbutton Enclosures, Type 12, 4PB x 22.5mm...
Regular price
$244.13
Unit price
Description
Description
Designed for pushbuttons and switches, the extra depth of these enclosures accommodates additional pushbutton contact blocks.
Main Features
- Seams continuously welded and ground smooth
- Captivated cover screws thread into sealed wells
- Bonding provision on cover
- Grounding nut in body of enclosure
- Oil-resistant gasket
- Enclosures with more than one column of pushbutton holes have internal detachable hinge to hold cover open during installation
- External welded-on mounting brackets for easy installation
- Factory stamped 4-way pushbutton holes
- 22.5-mm size holes
Specifications
Specifications
Industry Standards
- UL 508A Listed; Type 12, 13; File No. E61997
- cUL Listed per CSA C22.2 No. 94; Type 12, 13; File No. E61997
- NEMA/EEMAC Type 12, 13
- CSA File Number 42186: Type 12
- IEC 60529, IP65
Specifications
| Height | 9.5 in / 241 mm |
|---|---|
| Width | 2.75 in / 70 mm |
| Depth | 3.5 in / 89 mm |
| Protection Rating | NEMA Type 12; NEMA Type 13; IP65 |
| Material | Mild Steel |
| Hole Quantity | 4 |
| Mounting | 10.00 x 1.88 in / 254 x 48 mm |
| Overall Dimensions | 10.50 x 2.97 in / 267 x 75 mm |
| Color | Gray |
| Color Code | ANSI 61 |
| Finish | Powder Coated |
| Thickness | 14 ga / 1.9 mm |
| BULLETIN NUMBER | PB1 |
