Hoffman ECL603537VP | ComLine VM Cabinet, 600x350x375mm, Lt Gray, A...
Regular price
$4,037.45
Unit price
Brand: Hoffman
|
SKU:
954620
Regular price
$4,037.45
Unit price
Description
Description
ComLine Vertical-Mount Cabinet is ideal for telecommunications industry applications. The unique vertical orientation of the 19-inch rack equipment makes this cabinet especially suitable for pole-mount applications. The narrow cabinet width also makes it very wind resistant.
Main Features
- Vertically oriented 19-inch equipment mounting creates a compact, wind-resistant cabinet
- Integral solar shield reduces solar heat load
- Right-side, solid gland plate can be removed and modified as needed
- 6 RU Rack has square hole spacing per EIA universal standards; order cage nuts separately
- Quarter-turn, multi-point, vault-style latching system increases protection and security
- 160-degree door opening with quick-release, retained hinge pins
- Body and door ground studs for bonding and grounding
- Foam-in-place seamless gasket for superior protection against dust and liquid ingress
- Back is prepared with mounting provisions for standard panels
- Mounts to poles or walls
Specifications
Specifications
Industry Standards
- UL 508A Listed; Type 3, 3R, 4, 4X, 12; File No. E61997
- CSA: Type 3, 3R, 4, 4X, 12
- NEMA/EEMAC Type 3, 3R, 4, 4X, 12
- EC60529, IP66
- Designed to meet Telcordia NEBS GR-487, GR-63 and IEC 48D
Related Accessories
- Catalog #: EGVM
- Catalog #: EGVM1
- Catalog #: EGVM2
- Catalog #: EGVM3
- Catalog #: EGBB1
- Catalog #: EGBB2
- Catalog #: EDSK
- Catalog #: ELHP
Specifications
| Height | 23.62 in / 600 mm |
|---|---|
| Width | 13.78 in / 350 mm |
| Depth | 14.76 in / 375 mm |
| Protection Rating | NEMA Type 12; NEMA Type 4; NEMA Type 4X; NEMA Type 3; NEMA Type 3R; IP66 |
| Material | Aluminum |
| Rack Units Vertical | 5 |
| Color | Light Gray |
| Color Code | RAL 7035 |
| Finish | Powder Coated |
| Thickness | 0.1 in / 2.5 mm |
| Weight | 29.85 lb |
| BULLETIN NUMBER | DCOM |
